Constant Pressure Water Supply System Non-negative Pressure Water Lifting Supply System
Constant Pressure Water Supply System Non-negative Pressure Water Lifting Supply System
Constant Pressure Water Supply System Non-negative Pressure Water Lifting Supply System
Constant Pressure Water Supply System Non-negative Pressure Water Lifting Supply System
Constant Pressure Water Supply System Non-negative Pressure Water Lifting Supply System
Constant Pressure Water Supply System Non-negative Pressure Water Lifting Supply System
Constant Pressure Water Supply System Non-negative Pressure Water Lifting Supply System
Constant Pressure Water Supply System Non-negative Pressure Water Lifting Supply System
Specifications
Brand Name :
readycome
Model Number :
RDC-WS
Certification :
rohs
MOQ :
1 sets
Price :
￥31000 usd/sets 1-4 sets
Payment Terms :
D/A,D/P,T/T
brand name :
Readycome
application :
Commercial Buildings, Developing World Water Solutions, Family Homes, Food and Beverage Industry, Industrial Boilers, Industrial Utilities, Irrigation and Agriculture, Pharmaceutical industry, Washing and Cleaning, Water Distribution
Function :
High Efficiency Low Cost
Application :
Residential, commercial, and industrial use
Product Function :
Supply clean and safe water
Product Type :
Water Supply Equipment
Features :
Durable/Corrosion-resistant/Easy to install
Size :
Various sizes available
Description

Constant Pressure Water Supply System Non-negative Pressure Water Lifting Supply System


Parameters


Scope of application: It is applicable to situations where the pressure of the municipal pipeline network is ≥0.2MPa, and can meet the water supply demands of buildings of different heights and different water consumption.

Water supply pressure: It can be adjusted according to the user's requirements, generally ranging from 0.2 to 1.6MPa.

Flow range: Depending on different models and specifications, the flow range varies from tens of cubic meters per hour to hundreds of cubic meters per hour.

Power range: The power range of the water pump that comes with the equipment is usually 1.5kW - 75kW, and it can be selected and configured according to actual needs.

Constant flow compensation capacity: Generally 0.5m³ - 50m³, the specific capacity is determined according to the model of the equipment and design requirements.

Control mode: Advanced PLC variable frequency speed control and intelligent control system are adopted, which can realize the automatic operation and remote monitoring of the equipment.


Residential water
 Public places
Constant Pressure Water Supply System Non-negative Pressure Water Lifting Supply System Constant Pressure Water Supply System Non-negative Pressure Water Lifting Supply System
Commercial buildings Irrigation
Constant Pressure Water Supply System Non-negative Pressure Water Lifting Supply System Constant Pressure Water Supply System Non-negative Pressure Water Lifting Supply System
Manufacturing Industrial systems
Constant Pressure Water Supply System Non-negative Pressure Water Lifting Supply System Constant Pressure Water Supply System Non-negative Pressure Water Lifting Supply System




Water pump unit
Stainless steel
flow stabilizer tank
Diaphragm pneumatic tank
Frequency conversion
control cabinet
The pump body and base are made of 304/316
stainless steel, which can
resist general acid and alkali corrosive media. Excellenthydraulic model and advanced manufacturing process improves the performance and service life of the pump.
Food-grade stainless steel flow stabilizer tank can help water supply and use efficiently while eliminating the negative pressure
of the pipeline network and avoiding water been polluted. It is of strong corrosion-resistant and heat-resistant not only durable but also keep the water safe and healthy.
Diaphragm pneumatic tank can bear heavy pressure with reinforced diaphragm air bladder and fixed with thickened plate and 6 strong nuts. Its threaded weld ports is made of 304 stainless steel and the internal filter mesh is set to prevent clogging.
Frequency conversion control cabinet adopts famous trusted brand frequency converter and human-machine interface touch screen. The
frequency converter can automatically start and stop, constant pressure mode and other functions when the system is in lack or overload protection.


Constant Pressure Water Supply System Non-negative Pressure Water Lifting Supply System

Constant Pressure Water Supply System Non-negative Pressure Water Lifting Supply System

Constant Pressure Water Supply System Non-negative Pressure Water Lifting Supply SystemConstant Pressure Water Supply System Non-negative Pressure Water Lifting Supply System

Constant Pressure Water Supply System Non-negative Pressure Water Lifting Supply System
Constant Pressure Water Supply System Non-negative Pressure Water Lifting Supply System
Constant Pressure Water Supply System Non-negative Pressure Water Lifting Supply System
Why Choose Us
Constant Pressure Water Supply System Non-negative Pressure Water Lifting Supply System
Constant Pressure Water Supply System Non-negative Pressure Water Lifting Supply System

Factory Tour
We rely on professional technology and practical experience to provide professional intelligent water supply equipment, rainwater reuse equipment, sewage lifting equipment, oil-water separator equipment, water treatment equipment and other solutions and equipment engineering services, serving real estate, hotels and guesthouses, schools and hospitals, highways, enterprises and factories, rural centralized water supply in a number of industry sectors.
Team Sprite


Constant Pressure Water Supply System Non-negative Pressure Water Lifting Supply System
