Specifications
Brand Name :
BK
Model Number :
BKW6008
Certification :
ISO9001/ISO14001/CE
Place of Origin :
China
MOQ :
1 set
Price :
Negotiation
Payment Terms :
L/C, T/T
Supply Ability :
100 SETS per month
Delivery Time :
5 to 20 working days, depends on order amount and specification
Packaging Details :
Export standard wooden case
Name :
Roots Rotary Lobe Blower
Type :
Positive Displacement Roots Type, three lobes
Air capacity :
7.45-17.83m³/min
Discharge differential pressure :
60-100KPA
Motor power :
5.5-7.5/11-15/18.5-22/30/37-45KW
Discharge bore :
DN125 (5”)
Driven type :
motor driven, connected by belt and pulley
Installation type :
Vertical, horizontal available also
Weight (No Motor) :
305 KG
Speed :
850-1800 rpm
Cooling Water :
8 L/min
Shaft Power :
11.21-34.52 KW
Description

Roots Rotary Lobe Blower Featuring Tri Lobe Design and Water Cooling for Enhanced Performance in Industrial Applications

On the base of introduced technology from American, we developed BKW Series Roots blowers with tri-lobes and water cooling structure. The blower unit has a compact construction including blower, motor, inlet and discharge silencers, filter, flexible joints, relesf valve, check valve, and pressure gauge, and also can be equipped with acoustic enclosure and control devices.

Specifications

Model

BKW6008

Air capacity

7.45-17.83m3/min

Discharge differential pressure

60-100KPA

Rotary speed

850-1800rpm

Cooling water volume

8L/min

Motor type

5.5-7.5/11-15/18.5-22/30/37-45KW
380/400/415/440V, 3PHASES, 50/60HZ

Installation type

Standard: horizontal type.
Vertical type available for your option

N.W. of blower without motor

305kg

Packing size Approx.

Packing case for blower: 1.8*0.8*1.5m (L*W*H)


Applications

1. aeration waste water treatment

2. backwashing in sewage treatment

3. pneumatic conveying in cement plants

4. dust removal in power plant

Parameter sheet

Model Speed Inlet capacity (m3/min)and shaft power (KW)
0.6kgf/cm2 0.7kgf/cm2 0.8kgf/cm2 0.9kgf/cm2 1.0kgf/cm2
6000mmH2O 7000mmH2O 8000mmH2O 9000mmH2O 10000mmH2O
0.06Mpa 0.07Mpa 0.08Mpa 0.09Mpa 0.1Mpa
rpm m3/min KW m3/min KW m3/min KW m3/min KW m3/min KW
BKW6008 850 6.49 11.21 6.19 12.59
Port Dia: DN125(5") 1000 8.28 13.19 7.98 14.81 7.72 16.85 7.45 18.88
1150 10.07 15.17 9.77 17.03 9.51 19.37 9.25 21.72 9.01 24.06
1250 11.26 16.49 10.97 18.51 10.70 21.06 10.44 23.60 10.20 26.15
1400 13.06 18.46 12.76 20.73 12.49 23.59 12.23 26.44 11.99 29.29
1500 14.25 19.78 13.95 22.22 13.69 25.27 13.43 28.33 13.19 31.38
1650 16.04 21.76 15.74 24.44 15.48 27.80 15.22 31.16 14.98 34.52
1800 17.83 23.74 17.54 26.66 17.27 30.32

Structure of blower main body

Roots Rotary Lobe Blower Featuring Tri Lobe Design and Water Cooling for Enhanced Performance in Industrial Applications

Flow direction of cooling water

Roots Rotary Lobe Blower Featuring Tri Lobe Design and Water Cooling for Enhanced Performance in Industrial Applications

Assembling drawing of blower package

Roots Rotary Lobe Blower Featuring Tri Lobe Design and Water Cooling for Enhanced Performance in Industrial Applications

Outline Dimension

Standard accssory include:Inlet and outlet silencer,pressure gauge,base-frame,blower's pulley,motor'spulley,belt,belt guard,relief valve,check valve. The weight above are for standard accessories only,motor excluded. Dimension for blower,which is equipped with high voltage motor,will be supplied specially.
