Specifications
Brand Name :
BC
Model Number :
BC6005
Certification :
ISO9001 / ISO14001
Place of Origin :
Yixing, Jiangsu, China
MOQ :
1 set
Price :
USD 1550-2400 per set
Payment Terms :
L/C, T/T
Supply Ability :
150 sets / month
Delivery Time :
15 days
Packaging Details :
wooden case
material :
cast iron
pressure :
10 kpa - 80 kpa
colour :
customizable
port dia :
80 ( 3'' )
Description

5.5-22KW Three Lobe Roots Blower For Various Uses / Roots Style Blower

1,BC Three Lobe Roots Blower Introduction

Roots Blower is a cubage blower ,and it discharges a fixed amount of air in proportion to its rotation speed. Every rotation, there is two lobes to finish three times absorbing and discharging air.Compared with two lobes blower, it is of less air pulses, smaller load change, higher strength, lower noise and vibration. Two parallel shafts have three lobes each , all the lobes keep small clearance with each other and housing inside . Every lobes rotation , a certain air will be absorbed at inlet and transferred from the housing inside surface to blower's discharge port. Two shafts will be turned by the timing gears, no any touching between lobes , so it can be turned at high speed without any lubrication inside. It has the following characteristics : Simply configuration ; running smoothly ; good performance stabilization . It has been widely applied in various industries.

2,BC Type Performance Parameters Sheet

Type Port Dia Speed Inlet airflow(m3/min)and shaft power(KW)at different conditions
10kpa 20kpa 30kpa 40kpa 50kpa 60kpa 70kpa 80kpa
rpm m3/min KW m3/min KW m3/min KW m3/min KW m3/min KW m3/min KW m3/min KW m3/min KW
BC6005 80(3'') 850 5.01 1.66 4.58 2.95 4.26 3.90 3.99 4.87 3.75 6.00 3.54 7.13
1000 6.07 1.95 5.65 3.47 5.33 4.59 5.05 5.73 4.82 7.06 4.60 8.39 4.40 9.45 4.22 10.73
1150 7.13 2.24 6.71 3.99 6.39 5.28 6.11 6.59 5.88 8.12 5.67 9.65 5.46 10.87 5.29 12.33
1250 7.84 2.44 7.42 4.34 7.10 5.74 6.82 7.16 6.59 8.82 6.38 10.49 6.17 11.82 5.99 13.41
1400 8.91 2.73 8.48 4.86 8.16 6.43 7.89 8.02 7.65 9.88 7.44 11.74 7.23 13.24 7.06 15.02
1500 9.61 2.92 9.19 5.21 8.87 6.89 8.59 8.60 8.36 10.59 8.15 12.58 7.94 14.18 7.76 16.09
1650 10.68 3.22 10.25 5.73 9.93 7.58 9.66 9.46 9.42 11.65 9.21 13.84 9.00 15.60 8.83 17.70
1800 11.74 3.51 11.31 6.25 11.00 8.27 10.72 10.32 10.49 12.71 10.27 15.10 10.07 17.02 9.89 19.31

3,Structure Drawings

5.5-22KW BC Type Tri Lobe Roots Blower For Various Uses / Roots Style Blower

1) Working smoothly as helical timing gears is adopted.

2) It is flexible mounting ways because of the same structure in inlet and outlet.

3) It adopts more reasonable bearing structure, which can increase the bearing operation life.

4) It is low noise, vibration and energy consumption.

4,Optional Accessories

1)Discharge Silencer ( vertical airflow )

5.5-22KW BC Type Tri Lobe Roots Blower For Various Uses / Roots Style Blower

2) Flexible Joint

5.5-22KW BC Type Tri Lobe Roots Blower For Various Uses / Roots Style Blower

3) AD Type check valve with machined surface sealed

5.5-22KW BC Type Tri Lobe Roots Blower For Various Uses / Roots Style Blower

5,Company brief

By advanced production & test equipment, technology and management method introduced from abroad, by advanced management software,

B-Tohin Machine ( Jaingsu ) Co.,Ltd. is committed to the production of high efficient and energy-saving blowers. And it's our sincere wish that we

can supply high-quality products and good service.
