3900m3 / Hour DN200 Roots Rotary Lobe Air Compressor and Blower 100KPA
3900m3 / Hour DN200 Roots Rotary Lobe Air Compressor and Blower 100KPA
3900m3 / Hour DN200 Roots Rotary Lobe Air Compressor and Blower 100KPA
3900m3 / Hour DN200 Roots Rotary Lobe Air Compressor and Blower 100KPA
3900m3 / Hour DN200 Roots Rotary Lobe Air Compressor and Blower 100KPA
3900m3 / Hour DN200 Roots Rotary Lobe Air Compressor and Blower 100KPA
3900m3 / Hour DN200 Roots Rotary Lobe Air Compressor and Blower 100KPA
3900m3 / Hour DN200 Roots Rotary Lobe Air Compressor and Blower 100KPA
3900m3 / Hour DN200 Roots Rotary Lobe Air Compressor and Blower 100KPA
3900m3 / Hour DN200 Roots Rotary Lobe Air Compressor and Blower 100KPA
3900m3 / Hour DN200 Roots Rotary Lobe Air Compressor and Blower 100KPA
3900m3 / Hour DN200 Roots Rotary Lobe Air Compressor and Blower 100KPA
Specifications
Brand Name :
BK
Model Number :
BKW9020S
Certification :
ISO9001/ISO14001/CE
Place of Origin :
China
MOQ :
1 set
Price :
Negotiation
Payment Terms :
L/C, T/T
Supply Ability :
50 SETS per month
Delivery Time :
5 to 20 working days, depends on order amount and specification
Packaging Details :
Export standard wooden case
Name :
Roots Rotary Lobe Blower
Type :
Positive Displacement Roots Type, three lobes
Air capacity :
40.72-73.32 m³/min
Discharge differential pressure :
60-100KPA
Motor power :
30-132W
Discharge bore :
DN200(8”)
Driven type :
motor driven, connected by belt and pulley
Installation type :
horizontal, vertical available also
Description


DN200 Roots Rotary Lobe Blower, 3900m3/hour, 100KPA lobe air compressor

BKW roots blower is a kind of higher boost pressure product. It can be used for various industries, such as for separating small particles and algae in groundwater, recovering valuable products in industrial sewage such as paper pulp and secondary sedimentation tank to separate and concentrate suspended particles and sludge.

Specifications

Model

BKW9020S

Air capacity

40.72-73.32m3/min

Discharge differential pressure

60-100KPA

Rotary speed

1000-1500rpm

Cooling water volume

15 L/min

Motor type

30-132KW
380/400/415/440V, 3PHASES, 50/60HZ

Installation type

Standard: horizontal type.
Vertical type available for your option

N.W. of blower without motor

800kg

Packing size Approx.

2.62*1.78*2.45m (L*W*H)


Features
1. High quality standards
2. Technical customization (size, pressure, design, accessories)
3. CNC machinery grinding.
4. Manual assembly.
5. Fewer vibrations transmitted through the lobe, for longer-lasting shafts, gears and bearings.

Parameter sheet

Model Speed Inlet capacity (m³/min)and shaft power (KW)
0.6kgf/cm2 0.7kgf/cm2 0.8kgf/cm2 0.9kgf/cm2 1.0kgf/cm2
6000mmH2O 7000mmH2O 8000mmH2O 9000mmH2O 10000mmH2O
0.06Mpa 0.07Mpa 0.08Mpa 0.09Mpa 0.1Mpa
rpm m3/min KW m3/min KW m3/min KW m3/min KW m3/min KW
BKW9020S 1000 44.70 59 43.60 65.83 42.58 72.66 41.62 79.49 40.72 86.33
1050 47.61 61.95 46.52 69.12 45.50 76.29 45.54 73.47 43.64 90.64
1150 53.50 66.49 52.57 74.19 51.71 81.89 50.90 89.59 50.13 97.29
1250 59.17 72.27 58.24 80.64 57.37 89.01 56.56 97.38 55.79 105.70
1400 67.66 80.94 66.73 90.32 65.86 99.69 65.05 109.1 64.28 118.40
1500 73.32 86.72 72.39 96.77 71.52 106.80 70.71 116.9 69.94 126.90
Port Dia: DN200 (8") Cooling water volume: 15 L/min

Structure of blower main body

3900m3 / Hour DN200 Roots Rotary Lobe Air Compressor and Blower 100KPA

Flow direction of cooling water

3900m3 / Hour DN200 Roots Rotary Lobe Air Compressor and Blower 100KPA

Assembling drawing of blower package

3900m3 / Hour DN200 Roots Rotary Lobe Air Compressor and Blower 100KPA

Standard supply of scope

1. shaft blower
2. inlet silencer (with air filter)
3. outlet silencer
4. relieve valve
5. check valve
6. flexible joint
7. pressure gauge
8. blower pulley and motor pulley
9. V-belt
10. belt cover
11. public base
12. motor
