CE 5KW Dn32 Residential Geothermal Heat Pump MDS water
CE 5KW Dn32 Residential Geothermal Heat Pump MDS water
CE 5KW Dn32 Residential Geothermal Heat Pump MDS water
CE 5KW Dn32 Residential Geothermal Heat Pump MDS water
CE 5KW Dn32 Residential Geothermal Heat Pump MDS water
CE 5KW Dn32 Residential Geothermal Heat Pump MDS water
CE 5KW Dn32 Residential Geothermal Heat Pump MDS water
CE 5KW Dn32 Residential Geothermal Heat Pump MDS water
Specifications
Brand Name :
Shenglin
Model Number :
MDS series
Certification :
CE
Place of Origin :
China
MOQ :
1 pcs
Price :
780~1500USD
Payment Terms :
T/T, Western Union
Supply Ability :
1000 PCS/month
Delivery Time :
15~20 days
Packaging Details :
Plywood case
COP :
4
Compressor :
Panasonic or Copeland Brand
Heat exchanger type :
One plate type, one coil type
Application :
House, Appartment, School, Hospital, Villa
Supply power :
220V/1PH/50Hz
Refrigerant :
R22/R417A/R404A/R407C/R410A
Working ambient temperature :
-15 ° C~ 45 ° C
Warranty :
1 Year
Description

CE Certificated Geothermal Source Heat Pumps

Feature:

1. Reliable compressor with R410a or R407C refrigerant.
2. Water exchanger equipped with shell and coil heat exchanger, reliable brand
stainless steel plate exchanger.
3. Soft start control for single phase power supply models.
4. Water flow switch equipped for water flow protection.
5. Careful protection functions such as: high pressure, low pressure, overheating,
overload ant freezing, phase order, discharge temp, etc.
6. Wilo water pump installed inside.
7. Flow switch for wat er flow protection.
8. Intelligent controller, and adjustment by quick mind microprocessor

Technical paramater:

Description
Geothermal heat pumpMODELUnitMDS15D
Rated heating capacityKW5
Hot water supplyL/h100
Average heating input powerKW1.2
Rated heating input currentA6
Max outlet water temp℃60
COP 4
PowerV/Hz220V/50
NoiseDb(a)50
DimensionW*D*Hmm657×557×765
Packing sizeW*D*Hmm737×637×915
Unit weightKG75
Working air temp range℃(-40℃)—45℃
compressorType Panasonic
water source heat exchangerType Plate heat exchange
Pipe sizeDN25
Hot water side heat exchangeType Coil heat exchanger
Water flowL/H2000L/h
Water pressure downKpa30
Pipe sizeDN25
Geothermal heat pumpMODELUnitMDS20D
Rated heating capacityKW7.5
Hot water supplyL/h150
Average heating input powerKW1.8
Rated heating input currentA8
Max outlet water temp℃60
COP 4
PowerV/Hz220V/50
NoiseDb(a)50
DimensionW*D*Hmm657×557×765
Packing sizeW*D*Hmm737×637×915
Unit weightKG75
Working air temp range℃(-40℃)—45℃
compressorType Panasonic
water source heat exchangerType Plate heat exchange
Pipe sizeDN25
Hot water side heat exchangeType Coil heat exchanger
Water flowL/H2000L/h
Water pressure downKpa30
Pipe sizeDN25
Geothermal heat pumpMODELUnitMDS30D
Rated heating capacityKW12
Hot water supplyL/h260
Average heating input powerKW2.9
Rated heating input currentA13/6
Max outlet water temp℃60
COP 4
PowerV/Hz220V/380V/50
NoiseDb(a)50
DimensionW*D*Hmm657×557×765
Packing sizeW*D*Hmm737×637×915
Unit weightKG122
Working air temp range℃(-40℃)—45℃
compressorType Copeland
water source heat exchangerType Plate heat exchange
Pipe sizeDN25
Hot water side heat exchangeType Coil heat exchanger
Water flowL/H3600L/h
Water pressure downKpa35
Pipe sizeDN25
Geothermal heat pumpMODELUnitMDS40D
Rated heating capacityKW16
Hot water supplyL/h380
Average heating input powerKW4
Rated heating input currentA9
Max outlet water temp℃60
COP 4.2
PowerV/Hz380V/50
NoiseDb(a)50
DimensionW*D*Hmm657×557×765
Packing sizeW*D*Hmm737×637×915
Unit weightKG160
Working air temp range℃(-40℃)—45℃
compressorType Copeland
water source heat exchangerType Plate heat exchange
Pipe sizeDN32
Hot water side heat exchangeType Coil heat exchanger
Water flowL/H4000L/h
Water pressure downKpa40
Pipe sizeDN25
