High Speed Shelf Panel Roll Forming Machine High Accuracy for Storage Rack Production
High Speed Shelf Panel Roll Forming Machine High Accuracy for Storage Rack Production
High Speed Shelf Panel Roll Forming Machine High Accuracy for Storage Rack Production
High Speed Shelf Panel Roll Forming Machine High Accuracy for Storage Rack Production
High Speed Shelf Panel Roll Forming Machine High Accuracy for Storage Rack Production
High Speed Shelf Panel Roll Forming Machine High Accuracy for Storage Rack Production
High Speed Shelf Panel Roll Forming Machine High Accuracy for Storage Rack Production
High Speed Shelf Panel Roll Forming Machine High Accuracy for Storage Rack Production
Specifications
Place of Origin :
CHINA
Brand Name :
HENGFU
MOQ :
1 Piece
Packaging Details :
Plastic Film & Steel Wire Fixed
Delivery Time :
45Days
Payment Terms :
30% deposit by T/T in advance and 70% balance after inspection confirmation before shipment
Model NO. :
Shelf Panel Forming Machine
Certification :
CE, SGS
Accuracy :
High Accuracy
Security Properties :
Stable and Reliable
Warranty :
1 Year
Automaticity :
Highly Automatic
Economy :
High Efficiency
Package Size :
1800.00cm * 150.00cm * 150.00cm
Package Gross Weight :
7500.000kg
Description
High Speed Shelf Panel Roll Forming Machine

Dongguang Hengfu Roll Forming Machine Co., Ltd. presents a high-performance automatic warehouse shelf panel roll forming machine, engineered for stable, efficient, and high-precision production of metal shelf panels. This fully integrated production line combines feeding, de-cornering, roll forming, precise shearing and bending into one continuous workflow, delivering consistent profile quality, strong structural rigidity, and long service life.

This shelf forming machine is specially designed for processing Q235 galvanized sheet, ensuring excellent formability, surface finish, and structural strength for heavy-duty shelf panels. It supports flexible production of various shelf dimensions to meet diverse storage system requirements, and is widely applied in warehouse racks, supermarket shelves, industrial storage systems, and logistics distribution centers.

The machine features a heavy-duty construction for industrial-grade durability. It adopts an integral wall panel structure with 25mm thickness and a steel welded square tube frame, providing exceptional rigidity, low vibration, and stable operation during long-hour production.

Technical Specifications
Rolling material Q235 galvanized sheet
Spindle Φ80
Structural form Integral wall panel structure, thickness 25mm
Production discharging speed 0-10m/min (PLC frequency conversion speed regulation)
Transmission mode The motor drives the reducer and then drives the gear transmission
Control system A) Adopt programmable PLC control system and frequency converter for speed regulation.
B) Human-machine interface, touch screen display, easy and user-friendly operation
Frame Use steel welded square tube frame
Molding machine dimensions 18000mm*1500mm*1500mm
Mold Material is Cr12MOV, hardness HRC58-62°
Product Gallery
High Speed Shelf Panel Roll Forming Machine High Accuracy for Storage Rack Production High Speed Shelf Panel Roll Forming Machine High Accuracy for Storage Rack Production High Speed Shelf Panel Roll Forming Machine High Accuracy for Storage Rack Production
Frequently Asked Questions
What materials is this machine suitable for?
Cold-formed materials such as color-coated steel, galvanized steel, aluminum-magnesium-manganese alloy, and stainless steel.
Do you have customers for your equipment in our country?
Yes, we have established customers in the Middle East, North Africa, and various European countries.
What are the available cutting methods?
Hydraulic Flying Shear or Servo Tracking Flying Shear (Higher precision, faster speed, burr-free cuts).
Can it be integrated into a complete color steel production line?
Yes, it can form a fully automated line covering uncoiling, leveling, roll forming, shearing, and stacking.
Can a laminating machine be added?
Yes, it allows for an integrated production line combining lamination and forming.
