7 Feet Width 415V Roll Auto Spot Welder , Anti Alkali Roll Welding Machine
7 Feet Width 415V Roll Auto Spot Welder , Anti Alkali Roll Welding Machine
Specifications
Brand Name :
Huayang
Model Number :
R-DHW
Certification :
CE
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
20 sets/month
Delivery Time :
30 days
Packaging Details :
1.Machine will be covered with plastic film and fastened by steel wire in container. 2. Spare parts will be packed into carton box and fastened stable in container.
Product name :
Automatic Seven Feet 415V Roll Stainless Steel Spot Welding Machine
Final product :
Roll mesh
Pitch :
1/2", 1", 2", 3", 4"
Applicable Industries :
Manufacturing Plant, Construction works
Suitable wire to the machine :
Low carbon steel wire
Voltage :
220V/380V/415V/440V
Color :
Can Be Customized
Power Supply :
Three phase four electric
Current :
Alternate
Key Selling Points :
High Safety Level
Description

Automatic Seven Feet 415V Roll Stainless Steel Spot Welding Machine

1. Product description

Automatic seven feet 415v roll stainless steel spot welding machine is used for making wire mesh. Commissioning the machine in the factory and assembled complete assurance can be used immediately after purchase, no longer to assemble,complete accessories. Easy to operate, only one person can operate, lower labor costs.


2. Technical parameter

Model Mesh width Minimum mesh size (inch) Wire diameter(mm) Welding speed (rows/min) Roll mesh length (m) Other available mesh size (inch)
R- DHW 5feet 1/2x1/2 0.45-0.85 90-120 130 1/2x1, 1x1/2, 1x1, 2x2
R- DHW 5feet 1/2x1/2 0.6-1.3 90-120 110 1/2x1, 1x1/2, 1x1, 2x2
R- DHW 5feet 1/2x1/2 0.8-1.6 80-90 100 1/2x1, 1x1/2, 1x1, 2x2
R- DHW 5feet 1x1 0.45-0.85 90-120 130 1x2, 2x1, 2x2, 2x4
R- DHW 5feet 1x1 0.6-1.3 90-110 110 1x2, 2x1, 2x2, 2x4
R- DHW 5feet 1x1 0.8-1.6

90-110

 100 1x2, 2x1, 2x2, 2x4
R- DHW 5feet 1x1 1.4-2.6 80-90 80 1x2, 2x1, 2x2, 2x4

3. Application area


Automatic seven feet 415v roll stainless steel spot welding machine can be used for external wall insulation wire mesh, galvanized wire mesh, galvanized welded wire mesh , construction mesh, external wall insulation mesh, decorative mesh, anti- Split net. It is made of high-quality stainless steel wire, which is more resistant to acid, alkali, welding, beauty and versatility.

4. Advantages

a. At the same time, the machine is also equipped with automatic cutting mesh machine, when the machine finishes the mesh length according to the setting parameters, the mesh will be cut by the cutting mesh machine automatically.

b. Automatic mesh turning, stacking and conveying system.


c. Good quality and famous brand motor and gearbox, equipped with inverter.


d. Both longitude wire and weft wire can be fed from wire coils automatically.

e. We can design the machine according to your wire diameter,mesh hole size and so on.
