HB430 6.0mm Wear Resistant Steel Plate NM400 Grade Uses In Containers
HB430 6.0mm Wear Resistant Steel Plate NM400 Grade Uses In Containers
HB430 6.0mm Wear Resistant Steel Plate NM400 Grade Uses In Containers
HB430 6.0mm Wear Resistant Steel Plate NM400 Grade Uses In Containers
HB430 6.0mm Wear Resistant Steel Plate NM400 Grade Uses In Containers
HB430 6.0mm Wear Resistant Steel Plate NM400 Grade Uses In Containers
Specifications
Brand Name :
ZGMC
Model Number :
Wear Resistant Plate
Certification :
ISO TUV SGS BIS CE
Place of Origin :
Shandong China
MOQ :
3Tons
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram,OA
Supply Ability :
5000Tons Per Months
Delivery Time :
5-15days depend on the quantity
Packaging Details :
With iron sheet to pack the steel sheet and pallet .Also make the shipping marks on each bundles.
Product Name :
Wear resistant steel plate
Equivalent grade :
Hardox 400/Abrex 400/AR400
Thickness :
3-100mm
Thick Tolerance :
-0.2 ~0mm
Width :
1500-3000mm
Length :
3000-12000mm
Application :
Containers
Hardness :
360-440HB
Surface :
Galvanize/Spraying/Grinding/Polishing
Service :
Cutting/Sheet-metal working/Custom-made
Description
NM400 is a high-strength wear-resistant steel plate known for its excellent wear resistance and toughness. Here are some key features, applications, and common information about NM400:
Features:
Wear Resistance: NM400 exhibits exceptional resistance to abrasion, erosion, and impact, making it suitable for harsh working environments with high wear and tear.
High Strength: It possesses high strength and hardness, allowing it to withstand heavy loads and impact forces.
Weldability: NM400 offers good weldability, allowing for ease of fabrication and assembly.
Machinability: It can be machined using conventional methods, enabling the production of complex parts and components.
Applications:
Mining and Construction Machinery: NM400 is extensively used in mining equipment, earth-moving machinery, dump truck bodies, excavator buckets, and wear liners for crushers and chutes.
Material Handling: It finds applications in industries involving bulk material handling, such as conveyor systems, hoppers, and wear-resistant liners.
Cement and Steel Production: NM400 is utilized in cement plants, steel mills, and foundries for equipment subjected to abrasion and impact, including crushers, hoppers, and cyclones.
Recycling and Waste Management: It is applied in waste sorting and recycling equipment, shredders, and wear plates for waste containers and compactors.
Common Information:
Standard: NM400 complies with the Chinese standard GB/T 24186-2009 for wear-resistant steel plates.
Hardness: NM400 typically exhibits a hardness range of 360 to 440 HBW (Brinell hardness).
Thickness and Size: NM400 is available in thicknesses ranging from 3mm to 100mm, with common widths of approximately 1500mm to 3000mm and lengths of 3000mm to 12000mm.
International Equivalents: NM400 is comparable to internationally recognized wear-resistant steel grades such as Hardox 400 (Sweden) and AR400 (USA).
NM400's exceptional wear resistance, high strength, and versatility make it a preferred choice for various industries requiring durable and abrasion-resistant materials.
Chemical Composition Of NM 400 Plates
NM 400 Chemical Compositiom
Plate C Si Mn P S Cr Ni Mo B
thickness mm max % max % max % max % max % max % max % max % max %
3-(8) 0.15 0.7 1.6 0.025 0.01 0.3 0.25 0.25 0.004
8-20 0.15 0.7 1.6 0.025 0.01 0.5 0.25 0.25 0.004
(20)-32 0.18 0.7 1.6 0.025 0.01 1 0.25 0.25 0.004
(32)-45 0.22 0.7 1.6 0.025 0.01 1.4 0.5 0.6 0.004
(45)-51 0.22 0.7 1.6 0.025 0.01 1.4 0.5 0.6 0.004
(51)-80 0.27 0.7 1.6 0.025 0.01 1.4 1 0.6 0.004
(80)-130 0.32 0.7 1.6 0.025 0.01 1.4 1.5 0.6 0.004
Mechanical Properties for NM 400 High Tensile Plate
Mechanical properties of NM 400
Grade Mechanical Property Charpy V Impact Test
NM 400 Yield Tensile Elongation Degree longitudinal
Min Mpa Mpa Min % -40 J
1000 1250 10 45

HB430 6.0mm Wear Resistant Steel Plate NM400 Grade Uses In Containers
