12.3 inch Bar Type LCD Display 1024*255 LVDS 500 Nits Display Customized
12.3 inch Bar Type LCD Display 1024*255 LVDS 500 Nits Display Customized
12.3 inch Bar Type LCD Display 1024*255 LVDS 500 Nits Display Customized
12.3 inch Bar Type LCD Display 1024*255 LVDS 500 Nits Display Customized
12.3 inch Bar Type LCD Display 1024*255 LVDS 500 Nits Display Customized
12.3 inch Bar Type LCD Display 1024*255 LVDS 500 Nits Display Customized
Specifications
Brand Name :
ROGIN
Model Number :
LCMA-RX0123TB02-C050
Place of Origin :
Shenzhen
MOQ :
5
Price :
Price is negotiable.
Payment Terms :
T/T, L/C
Supply Ability :
Spot adequacy
Delivery Time :
6-8 weeks
Packaging Details :
Cartons or wooden cases
Panel Size :
12.3"
Resolution :
1024*255
Brightness :
500 (Typ.)
Operating Temp. :
-20~70℃
Active Area :
304.13*76.03mm (A.A)
Outline Dimension :
325.9*98.48*11.6mm
Name :
Bar Type LCD Display
Description

12.3 inch Bar Type LCD Display 1024*255 LVDS 500nits

Product Advantage ►

1. 3 set cutting machines, 2 advanced cutting production lines, the longest one can be cut to 1.7m (75 inch cutting).
2. Advanced cutting technology to ensure the yield and precision.
3. High reliability with same features as original panel.
4. High Anti-vibration.
5. Brightness can be customized (500-2500nit).
6. Long life time 50K hours(Typ), up to 80K hours.

Product Application ►

1. Commecial signage : Advertising and Price Shelves.
2. Public transportation: Bill board for Bus/Metro and light rail.
3. Guidance board, Lift advertising board.
4. Financial services. Bank call notice board.
5. Name card.
6. Advertising board on taxi.

12.3 inch Bar Type LCD Display 1024*255 LVDS 500 Nits Display Customized 12.3 inch Bar Type LCD Display 1024*255 LVDS 500 Nits Display Customized 12.3 inch Bar Type LCD Display 1024*255 LVDS 500 Nits Display Customized 12.3 inch Bar Type LCD Display 1024*255 LVDS 500 Nits Display Customized

Specifications ►

LCMA-RX0123TB02-C050

Brand Rogin
Series Bar Type LCD Display
Panel Size
 12.3 inch
Model
 LCMA-RX0123TB02-C050
Brightness
 500
Power Consumption (W)
 5.8
Resolution
 1024*255
Active Area
 304.13*76.03 mm
Overall Size
 325.9*98.48*11.6 mm
Viewing Angle
 /
Interface Definition
 LVDS (2 ch, 8-bit)
Backlight Type WLED
Contrast Ratio
 1000:1
Aspect Ratio
 4:0.99
Touch Panel Without
Operating Temperature
 -20~70℃

► Product catalog of bar type LCD display.pdf
