LVDS 1200nits High Brightness LCD Display 1280*800 10.1 Inch LCD Screen Advertising Outdoor
LVDS 1200nits High Brightness LCD Display 1280*800 10.1 Inch LCD Screen Advertising Outdoor
LVDS 1200nits High Brightness LCD Display 1280*800 10.1 Inch LCD Screen Advertising Outdoor
LVDS 1200nits High Brightness LCD Display 1280*800 10.1 Inch LCD Screen Advertising Outdoor
Specifications
Brand Name :
ROGIN
Model Number :
LCMA-RX0101GI02-C120
Place of Origin :
Shenzhen
MOQ :
5
Price :
Price is negotiable.
Payment Terms :
T/T, L/C
Supply Ability :
Spot adequacy
Delivery Time :
6-8 weeks
Packaging Details :
Cartons or wooden cases
Panel Size :
10.1"
Resolution :
1280*800
Brightness :
1200 (Typ.)
Aspect Ratio :
16:10 (W:H)
Active Area :
216.96*135.6mm (A.A)
Outline Dimension :
230.7*152.55*7mm
Description

10.1 inch High Brirghtness LCD Display 1280*800 LVDS 1200nits

Product Advantage ►

1. Brightness customization 700-5000cd/m2.
2. Outdoor sunlight readable.
3. Low power consumption.
4. High uniformity up to 85% .
5. Long lifetime, 50K hours(Typ), up to 80K hours
6. Aluminium backlight structure with good heat dissipation.
7. Wide temperature range up to -30°C-80°C.
8. High shock resistance and high stability.

Product Application ►

1. Bus Station Signage Board.
2. Intelligent Charging Pile.
3. Outdoor Electronic News Reading Board.
4. Intelligent Express Cabinet.
5. Vending Machine.
6. Commercial Advertising Machine.
7. Attractions Information Inquiry Machine.
8. Community Information Board.
LVDS 1200nits High Brightness LCD Display 1280*800 10.1 Inch LCD Screen Advertising Outdoor LVDS 1200nits High Brightness LCD Display 1280*800 10.1 Inch LCD Screen Advertising Outdoor LVDS 1200nits High Brightness LCD Display 1280*800 10.1 Inch LCD Screen Advertising Outdoor LVDS 1200nits High Brightness LCD Display 1280*800 10.1 Inch LCD Screen Advertising Outdoor

Specifications ►

LCMA-RX0101GI02-C120

LVDS 1200nits High Brightness LCD Display 1280*800 10.1 Inch LCD Screen Advertising Outdoor

Brand Rogin
Series High Brightness LCD Display
Panel Size(inch)
 10.1
Model
 LCMA-RX0101GI02-C120
Brightness
 1200
Power Consumption (W)
 8.8
Resolution
 1280*800
Active Area
 216.96*135.6
Overall Size
 230.7*152.55*7
Viewing Angle
 89/89/89/89
Interface Definition
 LVDS (1 ch, 6/8-bit)
Backlight Type WLED
Contrast Ratio
 800:1
Aspect Ratio
 16:10
Touch Panel Without
Operating Temperature
 (-20-70)
