Furukawa HD709-45-T38/T45 Shank Adapter 620mm T45 Thread Rock Drilling Rig Tool for Mining
Furukawa HD709-45-T38/T45 Shank Adapter 620mm T45 Thread Rock Drilling Rig Tool for Mining
Furukawa HD709-45-T38/T45 Shank Adapter 620mm T45 Thread Rock Drilling Rig Tool for Mining
Furukawa HD709-45-T38/T45 Shank Adapter 620mm T45 Thread Rock Drilling Rig Tool for Mining
Furukawa HD709-45-T38/T45 Shank Adapter 620mm T45 Thread Rock Drilling Rig Tool for Mining
Furukawa HD709-45-T38/T45 Shank Adapter 620mm T45 Thread Rock Drilling Rig Tool for Mining
Specifications
Brand Name :
MIROC
Model Number :
T45 620mm HD709
Certification :
ISO
Place of Origin :
CHINA
MOQ :
1
Price :
137
Payment Terms :
L/C,D/A,D/P,T/T,Western Union
Supply Ability :
3000
Delivery Time :
20-30
Packaging Details :
Wooden cases
Model NO. :
HD709
Material :
Alloy Steel
Surface Treatment :
Surface Carburizing
Length :
620mm
Thread :
T38/T45
Front End Diameter :
45mm
Compatblity :
Furukawa
Specification :
HD709-45-620
Description
Furukawa HD709-45-T38/T45 Shank Adapter
620mm T45 Thread Rock Drilling Rig Tool for Mining Applications
Material & Manufacturing Advantages
  • High-quality low-carbon alloy steel with precise alloy element ratios for improved hardenability
  • Advanced manufacturing technology including precision straightening to ensure straightness and reduced stress concentration
  • Carburization heat treatment + CNC machining for superior toughness and anti-fatigue strength in demanding drilling conditions
Product Customization
We design and produce various specifications of rock drill shank adapters according to your needs, available with either male or female threads as required.
Male vs. Female Shank Adapters
Type Thread Best Suited For
Male (more popular) External thread Drifting, tunneling, extension applications - where high bending stresses are present
Female Internal thread Limited drilling space - when total feed length is critical, e.g., underground roof bolting
Function & Performance Requirements
Transmits power from the rock drill to the drill stems with key property requirements including high toughness and no plastic deformation under repeated impact and torque.
Furukawa HD709-45-T38/T45 Shank Adapter 620mm T45 Thread Rock Drilling Rig Tool for Mining Furukawa HD709-45-T38/T45 Shank Adapter 620mm T45 Thread Rock Drilling Rig Tool for Mining
Technical Specifications
Thread Length (L) (mm) Diameter (D) (mm) Spline type Spline length (mm) Spline diameter (mm) Spline dimension (mm) Special feature
T38 620 45 Straight 93 62.75 9.67 Standard
T45 620 45 Straight 93 62.75 9.67 Standard
Furukawa HD709-45-T38/T45 Shank Adapter 620mm T45 Thread Rock Drilling Rig Tool for Mining Furukawa HD709-45-T38/T45 Shank Adapter 620mm T45 Thread Rock Drilling Rig Tool for Mining Furukawa HD709-45-T38/T45 Shank Adapter 620mm T45 Thread Rock Drilling Rig Tool for Mining
