T6 Series 101mm PDC Core Drill Bit with High Abrasion Resistance for Rock Drilling
T6 Series 101mm PDC Core Drill Bit with High Abrasion Resistance for Rock Drilling
T6 Series 101mm PDC Core Drill Bit with High Abrasion Resistance for Rock Drilling
T6 Series 101mm PDC Core Drill Bit with High Abrasion Resistance for Rock Drilling
T6 Series 101mm PDC Core Drill Bit with High Abrasion Resistance for Rock Drilling
T6 Series 101mm PDC Core Drill Bit with High Abrasion Resistance for Rock Drilling
Specifications
Brand Name :
MIROC
Model Number :
T6 101mm
Place of Origin :
CHINA
MOQ :
1
Supply Ability :
3000
Delivery Time :
20-30
Model NO. :
T6 101
Material :
PDC cutter, T.C.
Usage :
soil sampling, water well drilling, geotechnical studies
Core barrel design :
T6 series
Matrix Height :
6mm-25mm
Matrix Hardness :
Soft to Ultra-Hard
Advantage :
High Performance High Abrasion
Colors :
Optional
Specification :
T6-76 T6-86 T6-101 T6-116
Description
T6-101mm PDC Core Drill Bit Standard for Drilling
T6 series core bits are engineered for surface exploration applications when used with T6 series core barrels.
Advanced Impregnated Bit Technology
Impregnated diamond bits are designed to penetrate a comprehensive range of geological formations, from the softest to the hardest rock types. These bits are manufactured using high-quality synthetic diamonds uniformly distributed throughout a tungsten carbide matrix. During drilling operations, the matrix wears away evenly, ensuring continuous exposure of new, sharp diamond cutting points throughout the bit's operational lifespan. All impregnated bits feature tungsten carbide and diamond gauge protection for enhanced durability.
The optimal diamond size, concentration, and matrix composition are specifically engineered according to the hardness and abrasiveness characteristics of the target rock formations.
PDC Bit Applications
PDC (Polycrystalline Diamond Compact) bits serve as a high-performance alternative to traditional tungsten carbide bits and surface set diamond bits, particularly effective in non-consolidated and medium-hard rock formations.
Available Core Bit Sizes
Standard Sizes
AQ, BQ, BQ3, NQ, NQ2, NQ3 (NQTT), HQ, HO3 (HQTT), PQ, PQ3, T36, TT46, T2-46, TB56, TT56, T2-56, T2-66, T2-76, T2-86, T2-101, T6-76, T6-86, T6-101, T6-116, T6-131, T6-146, T6S-76, T6S-86, T6S-116, T6S-131, T6S-146, TBW, TNW, PWF, SWE, UWF, ZWF, AWG, BWG, NWG, HWG, AX, BX, NX, HX, EWM, AWM, BWM, NWM, HWM, AWT, BWT, NWT, HWT, LTK48, LTK60, BMLC, NMLC, HMLC, B36, B46, B56, B66, B76, B86, B101, B116, B131, B146, 36, 46, 56, 59, 75, 91, 110, 130, 150, 170, 219, 275
T6 Series 101mm PDC Core Drill Bit with High Abrasion Resistance for Rock Drilling T6 Series 101mm PDC Core Drill Bit with High Abrasion Resistance for Rock Drilling
Core Bit Types and Applications
Based on application requirements and cutting media specifications, KSQ manufactures six distinct types of core bits:
  • Impregnated Diamond Type
  • Surface Set Diamond Type
  • Tungsten Carbide Type
  • PDC Type
  • PCD Type
  • Electroplated Diamond Type
A complete drilling system typically includes core bits, reaming shells, core barrels, drill rods, and drilling rig equipment. Core bits are specifically designed for drilling various materials including rock, concrete, limestone, granite, marble, clay, basalt, schist, quartz, and other geological formations.
T6 Series 101mm PDC Core Drill Bit with High Abrasion Resistance for Rock Drilling T6 Series 101mm PDC Core Drill Bit with High Abrasion Resistance for Rock Drilling
