T6-101 Impregnated Diamond Core Bit with Standard Crown Profile and Face Discharge Waterways for Mining Exploration
T6-101 Impregnated Diamond Core Bit with Standard Crown Profile and Face Discharge Waterways for Mining Exploration
T6-101 Impregnated Diamond Core Bit with Standard Crown Profile and Face Discharge Waterways for Mining Exploration
T6-101 Impregnated Diamond Core Bit with Standard Crown Profile and Face Discharge Waterways for Mining Exploration
T6-101 Impregnated Diamond Core Bit with Standard Crown Profile and Face Discharge Waterways for Mining Exploration
T6-101 Impregnated Diamond Core Bit with Standard Crown Profile and Face Discharge Waterways for Mining Exploration
Specifications
Brand Name :
MIROC
Model Number :
T6-101
Certification :
ISO
Place of Origin :
CHINA
MOQ :
1
Supply Ability :
3000
Delivery Time :
20-30
Type :
Core Drill Bit
Material :
Diamond
Crown Profile :
Standard
Waterways :
Standard /Face Discharge /Turbo /Spiral
Applicaion :
All Conventional And Wireline Core Barrel
Use :
Mining Exploration Diamond Drilling
Description
T6-101 Impregnated Diamond Core Bit for Drilling
Product Description
T6 series core bits are designed for surface exploration when used with the T6 series core barrel.
Impregnated bits can penetrate a broad range of formations from the softest to the hardest rocks. They are manufactured with high-quality synthetic diamonds evenly distributed through a tungsten carbide matrix. During drilling, the matrix wears away evenly, resulting in continuous exposure of new, sharp diamond points throughout the bit's lifespan.
All impregnated bits feature T.C. and diamond gauge protection. The optimal diamond size, concentration, and matrix composition vary according to the hardness and abrasiveness of the rock formations being drilled.
Size Specifications
Size Outside Diameter (inch) Outside Diameter (mm) Inside Diameter (inch) Inside Diameter (mm)
T6-76 2.997/2.987 76.12/75.87 2.249/2.239 57.12/56.87
T6-86 3.391/3.381 86.13/85.88 2.643/2.633 67.13/66.88
T6-101 3.981/3.971 101.12/100.8 3.115/3.105 79.12/78.87
T6-116 4.575/4.560 116.20/115.8 3.667/3.657 93.14/92.89
T6-131 5.165/5.150 131.19/130.8 4.257/4.247 108.13/107.89
T6-146 5.755/5.740 146.18/145.8 4.847/4.837 123.18/122.89
T6-101 Impregnated Diamond Core Bit with Standard Crown Profile and Face Discharge Waterways for Mining Exploration T6-101 Impregnated Diamond Core Bit with Standard Crown Profile and Face Discharge Waterways for Mining Exploration
Applications
Impregnated diamond core bits (including NQ, HQ, T2-76 models) are widely used in mineral exploration and site investigation industries. The impregnated diamond core bit has become the most commonly used type in mineral exploration due to its advantages over other cutting media:
  • Extremely wide range of applications
  • Consistent performance across various rock formations
  • Long service life with continuous diamond exposure
T6-101 Impregnated Diamond Core Bit with Standard Crown Profile and Face Discharge Waterways for Mining Exploration T6-101 Impregnated Diamond Core Bit with Standard Crown Profile and Face Discharge Waterways for Mining Exploration T6-101 Impregnated Diamond Core Bit with Standard Crown Profile and Face Discharge Waterways for Mining Exploration T6-101 Impregnated Diamond Core Bit with Standard Crown Profile and Face Discharge Waterways for Mining Exploration
