Reverse Circulation Hammer for High Penetration Rates in 2 Inch to 12 Inch RC Drilling Operations
Reverse Circulation Hammer for High Penetration Rates in 2 Inch to 12 Inch RC Drilling Operations
Reverse Circulation Hammer for High Penetration Rates in 2 Inch to 12 Inch RC Drilling Operations
Reverse Circulation Hammer for High Penetration Rates in 2 Inch to 12 Inch RC Drilling Operations
Reverse Circulation Hammer for High Penetration Rates in 2 Inch to 12 Inch RC Drilling Operations
Reverse Circulation Hammer for High Penetration Rates in 2 Inch to 12 Inch RC Drilling Operations
Specifications
Brand Name :
MIROC
Model Number :
RC45HD RC Hammer
Certification :
ISO
Place of Origin :
CHINA
MOQ :
1
Supply Ability :
3000
Delivery Time :
20-30
Name :
Reverse Circulation Hammer
Use :
Ore Mining, Geothermal Drilling
Drilling :
Reverse Circulation Drilling
Hammers Bits :
Reverse Circulation Hammers and Bits
Specification :
2 Inch to 12 Inch
Description

Product Description
KSQ offers a complete line of Reverse Circulation hammers and spare parts, which can replace KSQ series Reverse Circulation Hammers & Bits. Hammers are available in a wide range of sizes and styles, to provide maximum performance and longevity on all RC drilling jobs.

Reverse Circulation hammers are designed with an inner sample tube that extends through the center and into the top of the hammer bit. The RC hammer exhausts the air between the bit splines and over the face of the bit. This forces the sample into the recovery holes in the face of the bit, through the center of the hammer and upward through the drill rod inner tubes to the surface for collection. The use of a shroud or collar is required when a RC hammer is used, to help direct the return air and cuttings up through the face of the bit.

Conventional DTH hammers can also be used in RC drilling operations, but increase the potential for sample loss and contamination. A conventional DTH hammer is used in conjunction with a cross-over sub located between the hammer and drill rod. The sample travels from the face of the bit up the outside of the hammer and into the cross-over sub.
The sub directs the sample up the center of the dual wall rods and to the surface.

REVERSE CIRCULATION DRILLING HAMMERS AND BITS

We offer a full range of reverse circulation down the hole hammers and bits, to suit all depths and ground conditions.

Due to its high-quality sample results, and speed of operation for shallower holes, reverse circulation drilling is becoming increasingly popular around the globe. In fact, it's the most widely accepted chip sampling method. This is largely due to our innovative designs, and we're continuing to develop the capabilities of this valuable sampling method. Partner with KSQ for your reverse circulation down hole hammer drilling.


Reverse Circulation Hammers​ Specification:

Reverse Circulation Hammers
Description Weight(kg)
RC45 RC55 RC65 RC52
1. Internal Circlip 0.03 0.04 0.05 0.04
2. Air Screen 0.35 0.44 0.65 0.44
3. Top Sub 6.50 9.65 20.00 9.65
4. "O" Ring 0.01 0.02 0.02 0.02
5. Sample Tube 5.10 6.72 12.50 6.75
6. Check Valve 0.25 0.68 0.85 0.68
7. Spring 0.04 0.12 0.10 0.12
8. "O" Ring 0.01 0.02 0.02 0.02
9. Air Distributor 0.85 1.48 3.50 1.48
10. "O" Ring 0.02 0.01 0.02 0.01
11. Internal Cylinder 2.20 4.12 4.20 4.12
12. Piston 8.50 16.90 24.00 16.90
13. External Cylinder 14.50 19.50 32.00 21.50
14. Guided Sleeve 1.20 0.90 5.50 1.90
15. "O" Ring - - - 0.02
16. Stop "O" Ring - - - 0.01
17. Stop Ring - - - 0.32
18. Shrout - - - 1.86
19. Drive Chuck 3.20 5.65 6.50 4.17
20. Bit Retaining Pin 0.01 0.15 0.30 -
21. Drill Bit 10.50 15.80 31.00 11.05
Technical Data
Model NRC45 NRC55 NRC65 NRC52
Length (Without Bit) 1020mm 1111mm 1250mm 1208mm
Weight (Without Bit) 94.00kg 66.50kg 110.00kg 70.00kg
External Diameter φ99mm φ126mm φ146mm φ126mm
Bit Shank NRC45 NRC55 NRC65 PR52
Hole Range φ114 - φ127mm φ133- φ152mm φ155- φ190mm φ133- φ146mm
Connection Thread As required As required As required As required
Working Pressure 1.0 - 3.0 Mpa 1.5 - 3.5 Mpa 1.5 - 3.5 Mpa 1.5 - 3.5 Mpa
Impact Rate at 17 Bar 30HZ 35HZ 28HZ 35HZ
Recommended Rotation Speed 25 - 40 r/min 25 - 40 r/min 25 - 40 r/min 25 - 40 r/min
Air Consumption 1.0Mpa: 8 m³/ min 1.7Mpa: 16 m³/ min 1.7Mpa: 20 m³/ min 1.7Mpa: 16 m³/ min
1.8Mpa: 12 m³/ min 2.4Mpa: 22 m³/ min 2.0Mpa: 26 m³/ min 2.4Mpa: 22 m³/ min
2.4Mpa: 16 m³/ min 3.0Mpa: 28 m³/ min 3.0Mpa: 35 m³/ min 3.0Mpa: 28 m³/ min


Advantages:
1. High penetration rates in all rock conditions
2. Quality samples from areas of lost circulation
3. Large, uncontaminated sample return
4. Increased longevity means lower cost per meter
5. The option of diamond-enhanced carbide bits for deep and abrasive drilling conditions, with no bits sharpening required
