Y26 Model Hand-Held Pneumatic Rock Drill with 60mm Piston Stroke and 28kg Weight for Efficient Drilling
Y26 Model Hand-Held Pneumatic Rock Drill with 60mm Piston Stroke and 28kg Weight for Efficient Drilling
Y26 Model Hand-Held Pneumatic Rock Drill with 60mm Piston Stroke and 28kg Weight for Efficient Drilling
Y26 Model Hand-Held Pneumatic Rock Drill with 60mm Piston Stroke and 28kg Weight for Efficient Drilling
Y26 Model Hand-Held Pneumatic Rock Drill with 60mm Piston Stroke and 28kg Weight for Efficient Drilling
Y26 Model Hand-Held Pneumatic Rock Drill with 60mm Piston Stroke and 28kg Weight for Efficient Drilling
Specifications
Brand Name :
MTH
Model Number :
Y26
Certification :
ISO 9001
Place of Origin :
CHINA
MOQ :
1 Piece
Price :
Negotiable
Payment Terms :
T/T,Western Union,MoneyGram
Supply Ability :
3000 pieces per month
Delivery Time :
10-15 days
Packaging Details :
wooden case
Name :
Pneumatic portable drilling machine/Hand held rock drill/jack hammer
Model :
Y26
Piston Stroke :
60mm
Application :
Surface Mining, Quarrying, Construction
Feature :
High Drilling Efficiency
Weight :
28kg
Description

Y26 Hand-Held Pneumatic Rock Drill Y26 Powerful Pneumatic Drilling Tool Jack Hammer

Product Introduction

Y26 hand-held rock drill machine has the advantages of small size, light weight, low gas consumption and so on , suitable for small mines, quarries, mountain roads, water conservancy construction and other projects a vertical downward or sloping blasting hole or secondary blasting hole is drilled in the surface layer. Y26 rock drill with independent strong air blowing system is suitable for drilling vertical downward blasting holes.

Technical specifications:

Weight 26 KG
Outside dimensions(L×W×H) 650*534*125 MM
Cylinder diameter 65 MM
Piston Stroke 70 MM
Working Pressure 0.4 Mpa
Impact energy ≥30 J
Impact frequency ≥23 HZ
Air consumption ≤47 L/S
Idling rotational speed ≥200 R/min
Noise ≤124 dB(A)
Working water pressure 0.3-0.35 Mpa
Air pipe inner diameter 19 MM
Water pipe inner diameter 13 MM
Rock drill hole diameter 34-42 MM
Rock drill hole depth 5 M
Shank Size 22*108 MM
