Hot Melt Glue Dispenser Automatic Hot Melt Glue Hot Melt Adhesive Strip Automatic Heating Pur Dispensing Machine

Specifications

Type :

Gluing Machine

Condition :

New

Price :

$4,500-4,600 / set

voltage :

220/110v

machinery test report :

Provided

Voltage :

220V or 110V

Weight :

95 KG

Brand Name :

Robotsung

Applicable Industries :

Building Material Shops, Manufacturing Plant, Food & Beverage Factory, Advertising Company

Warranty of core components :

1 Year

MOQ :

1 set

Application product :

Hot Melt Glue

application :

Machinery & Hardware, APPAREL, Textiles

dimension(l*w*h) :

51*68*68cm

warranty :

1 Year

core components :

Motor

Place of Origin :

Guangdong, China

driven type :

Electric

packaging type :

Case

key selling points :

Automatic

Glue type :

Hot Glue

Model Number :

YS-D461E

Name :

Hot Melt Adhesive Coating Machine

automatic grade :

Automatic

Certification :

Showroom Location :

None

video outgoing-inspection :

Provided

packaging material :

Wood

Function :

Glue Dispenser Glue Dispensing Machine

Description

Dispenser Robot Hot Melt Glue Dispensing Machine For Glass With Frame/high Quality Automatic Glue Dispensing Equipment

Auto Heater

It is suitable for glue in Block, flake, granular.

Auto Heater:

There is 5L tank,10L ,20L tank for your option.

Hot melt adhesive spraying equipment consists of main engine, throat pipe, gun body

module and other components.

The structure is shown as below:

The throat pipe is used to connect the main unit and the gun body module to ensure the

smooth transfer of the glue between them . The throat is heated by the electric heating

wire wound on it. The Pt100 temperature sensor detects the temperature of the throat

and feeds it back to the temperature control system to adjust the temperature to ensure

that the colloid temperature is stable at the set value. The technical parameters of the

throat are as follows:

Parameter value

Rated voltage

AC220V

Rated temperature

≤220C

Operating pressure

≤6.9MPa

Rupture pressure

≤51.7 MPa

Hot melt Gun will fix on Glue machine and doming glue automaticly:

Specification

Model	YS-D461E
Working area(X/Y/Zmm)	400/600/100
Max. Speed	500mm/sec
Resolution	0.01mm
Repeatability	+/-0.01mm
Display	5.7’ LCD
Drive mode	Micro Stepping Motor
Power	220V /110V
Working enviroment	Temperature:5-40 degrees Celsius Humidity:20-90%RH
Size(LWH)	460x450x480mm
Weight	70KG

OEM/ODM service offered

We are capable to manufacture dispensing equipment and liquid dispenser according to customer's drawings or samples. We are insisting on providing top quality products with competitive price. Please feel free to contact us. Welcome your inquiry.

Terms and conditions

Production lead time : 5-7 days

Payment terms:T/T in advance

other payment term can be discussed

Shipment term:Ex-work,or other shipping terms like FOB,CIF terms can be discussed.
