Specifications
Brand Name :
HUAQUN
Model Number :
HQ
Certification :
ISO9001,MSDS
Place of Origin :
Guangzhou, China
MOQ :
0.5 Tons
Price :
pending
Payment Terms :
L/C，T/T
Supply Ability :
Two thousand tons per month
Delivery Time :
3-5 working days
Packaging Details :
25kg per bag,40 bags per ton,25-27 tons per 1x20ft container
Item Name :
Thermoplastic Paint
Main Raw Material :
Petroleum Resin, Calcium Carbonate, Glass Beads
Appearance :
Powder
Application Area :
Road, Expressway and parking lot
Shelf life :
1 year
Advantage :
Quick Drying
Description

Reflective Thermoplastic Road Marking Paint with 20% Glass Beads for Pavement Marking

Description

What is thermoplastic road marking paint?

Thermoplastic road marking paint, also called hot melt marking paint, is a specialized type of powder paint that is made from thermoplastic materials. Thermoplastic paint is composed of a mixture of resin, pigments, glass beads, fillers, and various additives.

Thermoplastic powder paint requires specialized equipment like a preheater machine – hot melt machine which will heat it to 200 °C (392 °F) to melt the powder. When heated, this material becomes liquid and can be applied to road surfaces. Once it cools and solidifies, it forms a durable and long-lasting marking on the road.

The unique characteristic of thermoplastics is their ability to soften when heated and solidify when cooled. This property allows for easy application and ensures a long-lasting and robust finish on road surfaces.

Technical Specification

Density(g/cm3)1.8-2.3
Softening point (℃)90-125
Compressive Strength(MPa)≥12
Glass bead content(%)0-30%
Liquidity35±10
Packing25kg/bag
ColorWhite/Yellow/Blue/Red/Green/Customized
Executive standardJT/T280-2004/AASHTO/BS3262/Customized
AppearancePowder
Construction temperature180℃-220℃
Whiteness70-85(Customized)
Inverse coefficient50-550
Warranty12 months
Storage MethodAvoid light and moisture
Packing Size45×70×5CM


Product Advantage:

1. Higher adhesive strength: Special elastomer is added in our recipe of thermoplastic road marking paint in order to improve the adhesive strength.

2. Stronger crack resistance: Our recipe compounded a special additive which is seasoned with the temperature.Thus it avoids possible deformation of the melted film caused by nature temperature variation.

3.Bright color: Our recipe introduced high quality color filler with reasonable mixture proportion. And it helps thermoplastic paint lasts for years without color change.

4.Enhanced wet night visibility.

5. Immediate retroreflectivity.


Formula Customized

Customized Formula
Customized FormulaContent(Customized range)Characteristics
C5 Resin10%-22%Fluidity Toughness Hardness Adhesion
Titanium Dioxide0.5-10%0.5%-30%
Premixed glass beads0%-30%Reflective after surface wear
Calcium Carbonate Sand30%-80%Whiteness Wear-resistant Hardness
PE Wax1%-1.5%Cold and heat resistant
EVA0.5%-1%Crack resistance
Plasticizer1%-1.5%Toughness
