200KG 6M Lifting Height Hydraulic Boom Lift Double mast Aluminium
200KG 6M Lifting Height Hydraulic Boom Lift Double mast Aluminium
200KG 6M Lifting Height Hydraulic Boom Lift Double mast Aluminium
200KG 6M Lifting Height Hydraulic Boom Lift Double mast Aluminium
200KG 6M Lifting Height Hydraulic Boom Lift Double mast Aluminium
200KG 6M Lifting Height Hydraulic Boom Lift Double mast Aluminium
Specifications
Brand Name :
Visbull
Model Number :
GTWY6-200
Certification :
CE
Place of Origin :
China
MOQ :
1 unit
Price :
negotiation
Payment Terms :
L/C at sight, T/T . Western Union, MoneyGram
Supply Ability :
500 units per month
Delivery Time :
30 working days after received your deposit
Packaging Details :
Naked packing
Platform height maximum :
6m
Max. work Height :
7.8m
Platform Size :
1230*540mm
Paint: :
epoxy paint
Net weight :
520kg
Lift capacity :
200kg
Power source :
AC/DC
Material :
high-duty steel structure
Description

200KG 6M Lifting Height Hydraulic Boom Lift Double mast Aluminium

Description:

GTWSY series double mast lifts are deliver a new level of value and performance, more stable, versatility and affordable. Allowing two people stand on the platform, lead more productivity. All models are electric powered, no emission. With the clean design, GTWSY series are deal for electrical installation, painting, pumping, maintenance and cleaning.

Features:

1. Adopting hydraulic pressure and chain linkage, the easy structure is convenient for maintenance.

2. Small outside measure, light in weight and flexible mobility

3. 24v power supply is convenient and energy-conserving, protecting people safety.

4. 250kg of maximum lift capacity and 17.5m of working height provide more possibilities for aerial work.

5. The lifting processing can be controlled by the switch to control the lifting height.

6. The hydraulic system is popular brand, has good performance and rare maintenance.

7. Lifting system has emergency lowering valve. When the system is working and there is no power suddenly, it can make lift down safe.

Specifications:

Model GTWY6-200 GTWY8-200 GTWY10-200 GTWY12-200
Capacity kg 200 200 200 200
Max.Platform Height mm 6000 8000 10000 12000
Ground Clearance 80
Working Platform Size 1230x540 1350x540 1470x540
Unfolding Size 2230x1950 2230x2070 2230x2190
Power AC V 220
DC 24
Battery V/Ah 2x12/85
Charger V/A 24/10
Lifting Motor AC v/kw 220/1.1
DC 24/1.5
Overall Length mm 1460 1460 1580 1700
Overall Width 920
Overall Height 1980
Overall Weight AC kg 520 560 610 670
DC 550 590 640 700

200KG 6M Lifting Height Hydraulic Boom Lift Double mast Aluminium
