ISO / CE 53M Crawler Telescopic Upright Boom Lifts With 350KG Loading Capacity
ISO / CE 53M Crawler Telescopic Upright Boom Lifts With 350KG Loading Capacity
ISO / CE 53M Crawler Telescopic Upright Boom Lifts With 350KG Loading Capacity
ISO / CE 53M Crawler Telescopic Upright Boom Lifts With 350KG Loading Capacity
ISO / CE 53M Crawler Telescopic Upright Boom Lifts With 350KG Loading Capacity
ISO / CE 53M Crawler Telescopic Upright Boom Lifts With 350KG Loading Capacity
ISO / CE 53M Crawler Telescopic Upright Boom Lifts With 350KG Loading Capacity
ISO / CE 53M Crawler Telescopic Upright Boom Lifts With 350KG Loading Capacity
Specifications
Brand Name :
Visbull
Model Number :
KD-T53
Certification :
ISO/CE
Place of Origin :
China
MOQ :
1 unit
Price :
negotiation
Payment Terms :
L/C at sight, T/T . Western Union, MoneyGram
Supply Ability :
500 units per month
Delivery Time :
30 working days after received your deposit
Packaging Details :
Naked packing
Working height maximum :
53.3m
Platform height maximum :
51.3m
Lateral Outreach :
16.5m
Platform Size :
2.4×0.8×1.1m
Overall length :
8.715m
Total weight :
13600kg
Loading capacity :
350kg
Platform rotation :
180°
Turntable Swing :
360°continuous
Drive speed -stowed :
3.0km/h
Description

ISO / CE 53M Crawler Telescopic Upright Boom Lifts With 350KG Loading Capacity

Upright Boom Lifts 53M Crawler Telescopic Boom Lift KD-T53 Spider Boom Lift With 18.5KW Rated Power

Specifications:

—Made ​​of high strength steel, and the European production of hydraulic, control, parts;

—Pipeline all the built-in, to avoid the sun and rain or foreign objects tangled;
—Shape lightweight, low pressure rubber tracks on the ground, can travel, work on any ground;

—Outrigger separately controlled to bypass obstacles in a limited space work;

—Reliable torque control to ensure that the vehicle will not roll;

—Wired remote control walks, working bucket with 220V outlet;
—Small size, compact and flexible

Type

KD-T53

working height (m)

53.30

Platform height (m)

51.30

Safe load (kg)

350kgs

Size of platform (m)

2.4*0.8*1.1

Outreach (m)

16.5

Rotation of jib

180°

Rotation of work cage

180°

Rotation range

360°

Overall length (m)

8.715

Overall width (m)

1.58

Overall height (m)

1.98

Total weight (kg)

13600

Standard jacked area

30%

Speed (km/h)

0-3

Climability

30%

Power

18.5kw Diesel engine + 2.2kw motor

ISO / CE 53M Crawler Telescopic Upright Boom Lifts With 350KG Loading Capacity

ISO / CE 53M Crawler Telescopic Upright Boom Lifts With 350KG Loading Capacity
