10m Max Platform Height Towable Boom Lift with Hydraulic Outriggers and Outrigger Interlocks
10m Max Platform Height Towable Boom Lift with Hydraulic Outriggers and Outrigger Interlocks
10m Max Platform Height Towable Boom Lift with Hydraulic Outriggers and Outrigger Interlocks
10m Max Platform Height Towable Boom Lift with Hydraulic Outriggers and Outrigger Interlocks
10m Max Platform Height Towable Boom Lift with Hydraulic Outriggers and Outrigger Interlocks
10m Max Platform Height Towable Boom Lift with Hydraulic Outriggers and Outrigger Interlocks
10m Max Platform Height Towable Boom Lift with Hydraulic Outriggers and Outrigger Interlocks
10m Max Platform Height Towable Boom Lift with Hydraulic Outriggers and Outrigger Interlocks
Specifications
Brand Name :
Visbull
Model Number :
KD-P12
Certification :
ISO/CE
Place of Origin :
China
MOQ :
1 unit
Price :
negotiation
Payment Terms :
L/C at sight, T/T . Western Union, MoneyGram
Supply Ability :
500 units per month
Delivery Time :
30 working days after received your deposit
Packaging Details :
Naked packing
Working height maximum :
12m
Platform height maximum :
10m
Lateral Outreach :
4.5m
Platform Size :
0.9×0.8×1.1m
Wheelbase :
3.66m
Ground clearance-center :
43cm
Loading capacity :
200kg
Platform rotation :
100°
Turntable Swing :
350°continuous
Drive speed -stowed :
35km/h
Description

12M Factory Direct Towable Mounted Articulating Boom Lift KD-P12 With 200KG Rated Capacity

10m Max Platform Height Towable Boom Lift with Hydraulic Outriggers and Outrigger Interlocks

12M Factory Direct Towable Mounted Articulating Boom Lift KD-P12 With 200KG Rated Capacity

Specifications:

►Industry leading working envelope

►Articulating boom

►Multiple job site application, indoors and outdoors

►high and low operation panel

►Hydraulic outriggers and outrigger interlocks

►Hydraulic surge brakes

►350°non-continuous turntable rotation

►Made of high strength steel, famous china brand

►All pipelines put inside the machine, to aviod tangled sun and rain or other objects

►Protective covers for oil-tank, emergency controls and etc.

Description

KD-P12

Max. working height

12m

Max. platform height

10m

Loading capacity

200kgs

Lateral Outreach

4.5m

Jib rotation

100°

Turntable rotation

350°

Size of platform

0.9×0.8×1.1m

Overall stowed length

5.85m

Overall stowed width

1.7m

Overall stowed height

2.26m

Total weight

1180kgs

Traveling speed

35km/h

standard power source

Electric 220V AC power

optional power sources

Diesel engine or Battery

10m Max Platform Height Towable Boom Lift with Hydraulic Outriggers and Outrigger Interlocks
