16M Trailer Mounted Boom Lift Hydraulic Towable With 14M Platform Height KD-P16
16M Trailer Mounted Boom Lift Hydraulic Towable With 14M Platform Height KD-P16
16M Trailer Mounted Boom Lift Hydraulic Towable With 14M Platform Height KD-P16
16M Trailer Mounted Boom Lift Hydraulic Towable With 14M Platform Height KD-P16
16M Trailer Mounted Boom Lift Hydraulic Towable With 14M Platform Height KD-P16
16M Trailer Mounted Boom Lift Hydraulic Towable With 14M Platform Height KD-P16
16M Trailer Mounted Boom Lift Hydraulic Towable With 14M Platform Height KD-P16
16M Trailer Mounted Boom Lift Hydraulic Towable With 14M Platform Height KD-P16
Specifications
Brand Name :
Visbull
Model Number :
KD-P16
Certification :
ISO/CE
Place of Origin :
China
MOQ :
1 unit
Price :
negotiation
Payment Terms :
L/C at sight, T/T . Western Union, MoneyGram
Supply Ability :
500 units per month
Delivery Time :
30 working days after received your deposit
Packaging Details :
Naked packing
Working height maximum :
16m
Platform height maximum :
14m
Lateral Outreach :
4.5m
Platform Size :
0.95×0.65×1.1m
Overall stowed length :
6.5m
Total weight :
2000kg
Loading capacity :
200kg
Platform rotation :
100°
Turntable Swing :
350°continuous
Drive speed -stowed :
35km/h
Description

16M Trailer Mounted Boom Lift Hydraulic Towable With 14M Platform Height KD-P16

16M Trailer Mounted Articulated Boom Lift Hydraulic Towable Cherry Picker KD-P16 With 2Ton Operating Weight​

Specifications:

►Industry leading working envelope

►Articulating boom

►Multiple job site application, indoors and outdoors

►high and low operation panel

►Hydraulic outriggers and outrigger interlocks

►Hydraulic surge brakes

►350°non-continuous turntable rotation

►Made of high strength steel, famous china brand

►All pipelines put inside the machine, to aviod tangled sun and rain or other objects

►Protective covers for oil-tank, emergency controls and etc.

Description

KD-P16

Max. working height

16.00m

Max. platform height

14.00m

Loading capacity

200kgs

Lateral Outreach

5.50m

Jib rotation

100°

Turntable rotation

350°

Size of platform

0.95×0.65×1.1m

Overall stowed length

6.50m

Overall stowed width

1.53m

Overall stowed height

2.10m

Total weight

2000kgs

Traveling speed

35km/h

standard power source

Electric 220V AC power

optional power sources

Diesel engine or Battery

16M Trailer Mounted Boom Lift Hydraulic Towable With 14M Platform Height KD-P16

16M Trailer Mounted Boom Lift Hydraulic Towable With 14M Platform Height KD-P16
