Working Principle

• Waste Loading: Waste is fed through a widened, inclined top hopper with an automatic anti-blocking agitator, ensuring smooth material flow even for bulky or high-moisture waste.
• Vertical Compaction: Dual synchronous hydraulic cylinders deliver concentrated downward pressure, synergizing with gravity to compact loose waste into high-density blocks—achieving 10% higher compression efficiency than single-cylinder large models.
• Sealed Storage & Rapid Transfer: Compacted waste is pushed into one of two alternating sealed bins (eliminating waiting time for bin emptying). When full, the bin is hydraulically elevated, and an automatic high-speed push plate completes waste transfer to garbage trucks in 45 seconds.
• Eco-Friendly Treatment: Compression-generated sewage is collected in a closed circulation tank, filtered before municipal discharge; triple deodorization (spray + activated carbon + UV sterilization) eliminates odor and pathogenic bacteria.

System Configuration

• Main Structure: 16Mn high-strength steel frame (13mm thickness) with dual-cylinder synchronous compression + four reinforced guide columns, ensuring structural stability under continuous heavy-load operation.
• Hydraulic System: Energy-saving variable-displacement oil pump, wear-resistant alloy cylinders, and precision pressure-regulating valve group—optimized for 24/7 operation in complex urban environments.
• Control System: Touchscreen PLC controller with AI-assisted fault prediction, real-time data analytics, and multi-station centralized management (supports remote parameter adjustment via mobile/PC).
• Environmental Systems: Integrated sewage filtration, triple deodorization, and noise reduction (≤71dB) – meeting strict environmental standards of EU, Southeast Asia, and Middle East countries.
• Safety Systems: Multi-layer interlock protection, emergency stop matrix, anti-fall devices, anti-overload sensors, and anti-collision alarms—fully complying with ISO 14121 safety standards.

Ideal Applications

• Large urban core districts and regional waste transfer hubs
• High-density residential clusters + commercial complexes (shopping malls, office towers)
• Large industrial parks and logistics hubs
• Key Belt and Road metropolitan areas (e.g., Bangkok, Ho Chi Minh City, Kuala Lumpur)
• Municipal sanitation projects replacing outdated large-scale open waste sites
