25 Ton Pure Electric Compactor Garbage Truck with Zero Emission and Lithium Iron Phosphate Power Battery
25 Ton Pure Electric Compactor Garbage Truck with Zero Emission and Lithium Iron Phosphate Power Battery
25 Ton Pure Electric Compactor Garbage Truck with Zero Emission and Lithium Iron Phosphate Power Battery
25 Ton Pure Electric Compactor Garbage Truck with Zero Emission and Lithium Iron Phosphate Power Battery
25 Ton Pure Electric Compactor Garbage Truck with Zero Emission and Lithium Iron Phosphate Power Battery
25 Ton Pure Electric Compactor Garbage Truck with Zero Emission and Lithium Iron Phosphate Power Battery
25 Ton Pure Electric Compactor Garbage Truck with Zero Emission and Lithium Iron Phosphate Power Battery
25 Ton Pure Electric Compactor Garbage Truck with Zero Emission and Lithium Iron Phosphate Power Battery
25 Ton Pure Electric Compactor Garbage Truck with Zero Emission and Lithium Iron Phosphate Power Battery
25 Ton Pure Electric Compactor Garbage Truck with Zero Emission and Lithium Iron Phosphate Power Battery
25 Ton Pure Electric Compactor Garbage Truck with Zero Emission and Lithium Iron Phosphate Power Battery
25 Ton Pure Electric Compactor Garbage Truck with Zero Emission and Lithium Iron Phosphate Power Battery
Specifications
Model Number :
ZBJ5250ZYSDFBEV
Chassis model :
DFH1250DEV
MOQ :
1pc
Delivery Time :
45 working days
Motor power :
164 kW (rated), 308 kW (peak)
Payment Terms :
L/C,T/T
Price :
$10000-$70000
Battery type :
Lithium iron phosphate
Certification :
CE, ISO9001
Max speed :
89 kilometers per hour
Supply Ability :
5000pcs/year
Brand Name :
Bioclean
Vehicle model :
ZBJ5250ZYSDFBEV
Place of Origin :
China
Gross weight :
25000 kg
Packaging Details :
Containerizing
Description
Pure Electric Compactor Garbage Truck 25 Ton Rear Loader Waste Collection Vehicle
Basic Vehicle Overview

Model ZBJ5250ZYSDFBEV is a pure electric compressed garbage truck built on Dongfeng pure electric heavy-duty chassis (model DFH1250DEV). This zero-emission new energy sanitation vehicle operates without fuel consumption, fully complying with urban low-carbon environmental standards.

  • 3-axle 6x4 layout configuration
  • Maximum design speed: 89 km/h
  • Cab capacity: 2-3 passengers
  • Standard ABS anti-lock braking system
  • Satellite positioning driving recorder included
Weight Specifications
Parameter Specifications
Gross Vehicle Weight 25,000 kg
Curb Weight Options 16,650 kg / 16,800 kg / 16,950 kg
Rated Payload Options 8,220 kg / 8,155 kg / 8,070 kg / 8,005 kg / 7,920 kg / 7,855 kg
Axle Load Distribution Front: 7,000 kg max | Rear: 18,000 kg max
Dimensions
Dimension Specifications
Overall Length 11,325 mm / 11,720 mm / 11,643 mm / 11,528 mm
Overall Width 2,530 mm
Overall Height 3,465 mm
Wheelbase 5,000 mm + 1,350 mm
Approach/Departure Angle 20° / 8°
Tire & Suspension Configuration
  • Total tires: 10
  • Tire specifications: 11.00R20 18PR or 295/80R22.5 18PR
  • Suspension: 9-leaf front / 10-leaf rear
  • Side protective guards: Aluminum alloy, bolted to frame
  • Rear protective structure: Integrated with filling device
  • Ground clearance: 480 mm
Electric Power System

Zero Emission Operation - Fully electric system eliminates fuel consumption and exhaust emissions.

  • Battery: CATL lithium iron phosphate power battery
  • Motor: Permanent magnet synchronous motor (TZ460XS-LKM1901)
  • Rated power: 164 kW | Peak power: 308 kW
  • Charging: National standard DC fast charging compatible
  • Operation: Ultra-low noise, reduced daily operating costs
Compactor Superstructure & Hydraulic System

Fully sealed main garbage bin prevents sewage leakage and secondary pollution during transportation, featuring built-in independent sewage storage tank for leachate collection.

  • Compaction mechanism: Filling plate, sliding plate, and pushing shovel driven by high-pressure hydraulic cylinders
  • High compression ratio maximizes single trip loading capacity
  • Hydraulic system includes overpressure protection
  • Dual control: Electric control panel in cab + emergency manual buttons at rear platform
  • Optional attachments: Sealed bin door, rear camera, barrel lifting mechanism, high-pressure cleaning system
Cab Standard Equipment
  • Air conditioning system
  • Power windows and central door lock
  • Multi-functional LCD instrument panel
  • Bluetooth audio system
  • Split large-view rearview mirrors
  • Halogen headlights for day/night visibility
  • Manual tipping cab for maintenance access
  • Optional ETC on-board device available
