4 Ton Diesel Fork Lift Truck LG40DT
4 Ton Diesel Fork Lift Truck LG40DT
4 Ton Diesel Fork Lift Truck LG40DT
4 Ton Diesel Fork Lift Truck LG40DT
4 Ton Diesel Fork Lift Truck LG40DT
4 Ton Diesel Fork Lift Truck LG40DT
4 Ton Diesel Fork Lift Truck LG40DT
4 Ton Diesel Fork Lift Truck LG40DT
Specifications
Brand Name :
LonKing
Model Number :
LG40DT
Certification :
ISO CCC
Place of Origin :
Jinan China
MOQ :
1 unit
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
1000 units per month
Delivery Time :
Within 30-35 work days after receive order
Packaging Details :
Nude, Polished with wax before shipping on board
Product name :
4Ton Diesel Fork Lift Truck
Power type :
Diesel
Rated power (kW) :
60/2200
Total weight (kg) :
6400
Rated lifting weight (kg) :
4000
Load center distance (mm) :
500
Description

4Ton Diesel Fork Lift Truck LG40DT Fork Max.Lifting Height 3000mm 60Kw Engine Euro III

Features of 4Ton Diesel Fork Lift Truck LG40DT Fork Max.Lifting Height 3000mm 60Kw Engine Euro III

• Wider field of view of the gantry improves the strength and rigidity of the gantry and enhances the impact resistance

• Adopt Xichai CA4DX23 diesel engine (standard configuration), electronically controlled supercharging and intercooling, and the idling state can meet the needs of forklift operations

• The hydraulic system adopts load sensing technology (steering priority), small diameter steering wheel, reduces oil temperature by 10%, and saves fuel by 5%

• Step-type pointer instrument has water temperature gauge, oil gauge, chronometer and other alarm indicator lights, which is directly understandable, so that the working status is under control

• The hood opening angle is increased to 80 °, which makes maintenance more convenient; the hood lock is light and flexible to open, and the gas spring self-locking function ensures the safety of maintenance

• The seat conforms to the principles of ergonomics to reduce driver fatigue

Technical specification of 4Ton Diesel Fork Lift Truck LG40DT Fork Max.Lifting Height 3000mm 60Kw Engine Euro III

Standard specification
Model LG40D Power Diesel
Engine
model Xichai/CA4DX23-82GG3U Rated power (kW) 60/2200
Torque (N · m) 320/1400-1700 Displacement (L) 3.857
Overall specification
Total weight (kg) 6400 Rated lifting weight (kg) 4000
Load center distance (mm) 500 Maximum travel speed (no load / full load) (km / h) 23/24
Maximum lifting speed (mm / s) 520/460 Maximum grade(%) 23/20
Front tire 8.25-15-14PR Rear tire 7.00-12-12PR
Wheelbase (front wheel / rear wheel) (mm) 1180/1190 Ground clearance (mm) 170
Overall size
Maximum fork height (standard mast) (mm) 1090 Free lifting height (standard mast) (mm) 155
Thickness × Width × Length (fork) (mm) 1070×150×55 Mast tilt angle (forward / rear) (°) F6/R12
External dimensions: full length (to the vertical surface of the fork) (mm) 4145 External dimensions: width (frame width) (mm) 1480
External dimensions: max. lifting height of fork (mm) 3000 Min. turning radius (mm) 2720
Min. right angle channel (mm) 2480 Height of overhead guard (mm) 2250
Gate height (mm) 2245

4 Ton Diesel Fork Lift Truck LG40DT

4 Ton Diesel Fork Lift Truck LG40DT

After-sale Service:

• Detailed operating instructions also ,we have the Video Explanation

• Overseas engineer to provide technical service

• You can reach us at any time and get a rapid response

• Competent technical service

• Rapid and safe deliveries of spare parts
