5.5 Ton Loader ZL50GN With 3.2m3 Standard Bucket And Glass Protection
5.5 Ton Loader ZL50GN With 3.2m3 Standard Bucket And Glass Protection
5.5 Ton Loader ZL50GN With 3.2m3 Standard Bucket And Glass Protection
5.5 Ton Loader ZL50GN With 3.2m3 Standard Bucket And Glass Protection
5.5 Ton Loader ZL50GN With 3.2m3 Standard Bucket And Glass Protection
5.5 Ton Loader ZL50GN With 3.2m3 Standard Bucket And Glass Protection
Specifications
Model Number :
ZL50GN
Certification :
CE/ISO9001
Place of Origin :
China
MOQ :
1 unit
Price :
Negotiable
Payment Terms :
T/T, L/C
Supply Ability :
1000 units per month
Delivery Time :
7-10 days
Packaging Details :
nude
Engine Brand :
WEICHAI
Rated load :
5.5 ton
Bucket Capacity :
3.2m3
Power :
162kW/2200rpm
Tyre Size :
23.5-25-16PR
Origin :
China
Description

5.5 Ton Loader ZL50GN With 3.2m3 Standard Bucket And Glass Protection
ZL50GN loader is a well-known heavy-duty loader with the following advantages:
1. Powerful power and load capacity: Equipped with ’s latest engine and hydraulic transmission system, it provides reliable power output and excellent load capacity, and can Work efficiently under various working conditions.
2. High work efficiency: Using advanced hydraulic transmission system and equipped with quick shifting function, it can realize fast and flexible work operations and improve work efficiency.
3. Comfortable driving experience: The cab adopts humanized design and is equipped with air conditioning, vibration and noise reduction system and suspension seats, providing a comfortable working environment and driving experience.
4. Stable and reliable performance: The overall structure of the loader is strong and stable, and the hydraulic system uses high-quality hydraulic components to ensure the stability and reliability of the loader.
This model has a full-view cab that meets the requirements of various harsh working conditions. Beautiful appearance, no blind corners on site, wide door, and one-stop maintenance design make maintenance more convenient.
ZL50GN Wheel Loader Technical Specification

Description
Unit
Parameter value
Rated operating load
kg
5500
Bucket capacity
m³
3.2
Machine weight
kg
17500±300
Dump clearance at maximum lift
mm
3100~3780
Reach at maximum lift
mm
1100~1220
Wheel base
mm
3300
Tread
mm
2250
Max.breakout force
kN
175±5
Max.horse power
kN
160±5
Hydraulic cycle time-raise
s
≤6
Total hydraulic cycle time
s
≤10.5
Min. turning radius over tyres
mm
5925±50
Articulation angle
°
38
Gradeability
°
30
Tyre size
23.5-25-16PR
Overall machine dimension L×W×H
mm
8225×3016×3515
Model
WD10G220E21, Euro II
Rated Power
kW
162
Travel Speed
Ⅰ-gear(F/R)
13/17km/h
Ⅱ-gear(F)
41km/h
