35T Rail Guided Vehicles For Automated Material Handling Systems
35T Rail Guided Vehicles For Automated Material Handling Systems
35T Rail Guided Vehicles For Automated Material Handling Systems
35T Rail Guided Vehicles For Automated Material Handling Systems
35T Rail Guided Vehicles For Automated Material Handling Systems
35T Rail Guided Vehicles For Automated Material Handling Systems
Specifications
Brand Name :
RMK
Model Number :
KPX
Certification :
CE.ISO
Place of Origin :
CHINA
MOQ :
1 set
Price :
customized
Payment Terms :
T/T
Supply Ability :
300 set per year
Delivery Time :
60 days
Packaging Details :
tarp
Name :
35T Rail Guided Vehicles For Automated Material Handling Systems
load capacity :
35T
Wheel material :
steel
Brake :
Electric motor brakes
Max Capacity :
200ton
Application :
Warehouse, Factory, Hospital
Material :
Steel
Usage :
Transportation
Warranty :
1 Year
Description

35T Rail Guided Vehicles For Automated Material Handling Systems

We consider every detail of our customer’s needs for an easier integration of our AGV and rail guided vehicles in automated material handling systems of any scale and complexity.

After designing and manufacturing automatic shuttle carts for decades, we are perfectly aware of all the latest technologies on the market used for automation of in-house logistics and material handling in the variety of key industries including metalworking, mold, tooling, die and coil transport. We apply all modern methods of communication and data transmission including Wi-Fi and cable communications.

35T Rail Guided Vehicles For Automated Material Handling Systems35T Rail Guided Vehicles For Automated Material Handling Systems

We provide expertise also in all the most important power supply methods: automated shuttle carts powered by busbars, cable chains and drums, as well as battery powered automated trolleys featuring inductive cable embedded in the floor, with diesel engine or generator set.

All our automatic transfer cars follow the strictest standards in safety in terms of mechanical, as well as of electrical and electronic security.

RMK Rail Transfer Cart Models Will Perfectly Suit Your Needs For Coil Handling In Steel Industry, Concrete Manufacturing, Transportation In Factories, Warehouses, Ports And The Variety Of Hard Duty Fields Where Moving On Rails Is Required And Production Cycles Are Regular Both Time-Wise And Route-Wise. RMK Offers Modern Die Change Carts On Rails To Respond To Rapid Changes In Metalworking Industry And Reshape Its Logistics.

Technical parameters for Battery powered electric transfer carts KPX series
Model KPX-2t KPX-5t KPX-10t KPX-20t KPX-25t KPX-30t KPX-40t KPX-50t KPX-150t
Rated Load(t) 2 5 10 20 25 30 40 50 150
Table Size(mm) Length 2000 3500 3600 4000 4500 4500 5000 5500 10000
Width 1500 2000 2000 2200 2200 2200 2500 2500 3000
Height 450 500 500 550 600 600 650 650 1200
Wheel Base(mm) 1200 2500 2600 2800 3200 3200 3800 4200 7000
Rail Inner Gauge(mm) 1200 1435 1435 1435 1435 1435 1435 1435 2000
Wheel Diameter(mm) Ø270 Ø300 Ø300 Ø350 Ø400 Ø400 Ø500 Ø500 Ø600
Wheel Quantity 4 4 4 4 4 4 4 4 8
Ground Clearance(mm) 50 50 50 50 50 50 50 50 75
Running Speed(m/min) 0-25 0-25 0-25 0-20 0-20 0-20 0-20 0-20 0-18
Motor Power (Kw) 1 1.2 1.6 2.2 3 3.5 4 5 15
Battery Capacity (Ah) 180 180 180 180 250 250 300 330 600
Battery Voltage(V) 24 36 48 48 48 48 48 48 72
Running Time When Full Load 4.32 5.4 4.8 4 4 3.5 3.6 3.3 2.9
Running Distance for One Charge (Km) 6.5 8.1 7.2 4.8 4.8 4.2 4.3 4 3.2
Max Wheel Load (KN) 14.4 25.8 42.6 77.7 94.5 110.4 142.8 174 266
Reference Weight(t) 2.8 3.6 4.2 5.9 6.5 6.8 7.6 8 27
