RJ11 crystal head 6P6C crystal head DGKYDRJ111166F1A1WW041 (short body)
RJ11 crystal head 6P6C crystal head DGKYDRJ111166F1A1WW041 (short body)
RJ11 crystal head 6P6C crystal head DGKYDRJ111166F1A1WW041 (short body)
RJ11 crystal head 6P6C crystal head DGKYDRJ111166F1A1WW041 (short body)
RJ11 crystal head 6P6C crystal head DGKYDRJ111166F1A1WW041 (short body)
RJ11 crystal head 6P6C crystal head DGKYDRJ111166F1A1WW041 (short body)
RJ11 crystal head 6P6C crystal head DGKYDRJ111166F1A1WW041 (short body)
RJ11 crystal head 6P6C crystal head DGKYDRJ111166F1A1WW041 (short body)
RJ11 crystal head 6P6C crystal head DGKYDRJ111166F1A1WW041 (short body)
RJ11 crystal head 6P6C crystal head DGKYDRJ111166F1A1WW041 (short body)
Specifications
Brand Name :
DGKYD
Model Number :
DGKYDRJ111166F1A1WW041
Certification :
RoHS/CE/UL/FCC/CE/ISO9001/ISO14001
Place of Origin :
DongGuan of China
MOQ :
1 piece
Price :
Please contact us to get the latest price.
Payment Terms :
T/T,D/P,D/A,L/C,Western Union,MoneyGram
Supply Ability :
100K pcs/day
Delivery Time :
10 days
Packaging Details :
Tray in Carton
HOUSING :
P C
CURRENT RATING :
1.5 AMP
CONTACT RESISTANCE :
50 MILLIOHMS MAX.
TERMINAL :
1U"GOLD PLATED.
OPERATING TEMPERATURERESISTANCE :
-40℃～+80℃.
VOLTAGE RATINGVOLTAGE :
125 VAC RMS .
INSULATION RESISTANCE :
1000 MEGOHMS MIN @ 500 VDC.
DIELECTRIC STRENGTH :
1000 VAC RMS 50HZ, 1MIN.
SHELL :
C2680R-H,T=0.20MM,20~50U" MIN
type :
Crystal head
Description
RJ11 Crystal Head 6P6C Modular Connector
Part Number: DGKYDRJ111166F1A1WW041 (Short Body)
Professional-grade RJ11 6P6C modular connector designed for printed circuit board applications with side entry mounting.
Product Documentation
Download Product Specification Document (PDF)
Technical Specifications
ParameterSpecification
Part NumberDGKYDRJ111166F1A1WW041
BrandDGKYD/OEM/ODM
Place of OriginGuangdong, China
CertificationCE / UL / FCC / Reach / RoHS
Product TypeConnector-Modular
Connector StyleJack
Jack TypeRJ11
Connector TypeModular Jack
Latch StyleStandard
FilterWithout internal filter
LED OptionWithout LED
Panel StopsWithout Panel Stops
ShieldedYes
Applies ToPrinted Circuit Board
Performance SpeedStandard
Grounding OptionsPanel Ground and PCB Ground
Port Configuration1 port
Number of Positions6
Jack Configuration1 x 1
Terminals per Port6
Shield MaterialCopper Alloy preplated with Nickel
PCB Mounting OrientationSide Entry (Right Angle)
Contact Mating Area Plating MaterialGold 1u
Contact Base MaterialPhosphor Bronze
Solder Tail Contact Plating MaterialTin-Lead over Nickel
PCB Mounting StyleThrough Hole
Termination Method to PC BoardThrough Hole-Press-Fit
Board LockWith/Without Board Lock
Housing MaterialPC Polyester
Housing ColorWhite
Housing Material TemperatureStandard
UL Flammability RatingUL 94V-0
Product Images
RJ11 crystal head 6P6C crystal head DGKYDRJ111166F1A1WW041 (short body) RJ11 crystal head 6P6C crystal head DGKYDRJ111166F1A1WW041 (short body) RJ11 crystal head 6P6C crystal head DGKYDRJ111166F1A1WW041 (short body) RJ11 crystal head 6P6C crystal head DGKYDRJ111166F1A1WW041 (short body) RJ11 crystal head 6P6C crystal head DGKYDRJ111166F1A1WW041 (short body) RJ11 crystal head 6P6C crystal head DGKYDRJ111166F1A1WW041 (short body) RJ11 crystal head 6P6C crystal head DGKYDRJ111166F1A1WW041 (short body) RJ11 crystal head 6P6C crystal head DGKYDRJ111166F1A1WW041 (short body) RJ11 crystal head 6P6C crystal head DGKYDRJ111166F1A1WW041 (short body)
Frequently Asked Questions
  • Q: Are you a trading company or manufacturer?
    A: We are a manufacturer. Welcome to visit our factory.
  • Q: What about your lead time?
    A: For products in stock, delivery within 5-7 working days after payment. For customized and out-of-stock products, delivery time confirmed based on order quantity.
  • Q: Can you provide samples? Are they free?
    A: Yes. We typically provide 2-3 samples of standard products free for testing.
  • Q: Can I put my own logo on it?
    A: Yes. As a manufacturer with 11-year OEM experience, we are fully capable of customizing products for you.
