RM3-146A8M1F Stackable Rj45 Female Connectors LPJ17206BGNL In Ethernet Switch
RM3-146A8M1F Stackable Rj45 Female Connectors LPJ17206BGNL In Ethernet Switch
RM3-146A8M1F Stackable Rj45 Female Connectors LPJ17206BGNL In Ethernet Switch
RM3-146A8M1F Stackable Rj45 Female Connectors LPJ17206BGNL In Ethernet Switch
RM3-146A8M1F Stackable Rj45 Female Connectors LPJ17206BGNL In Ethernet Switch
RM3-146A8M1F Stackable Rj45 Female Connectors LPJ17206BGNL In Ethernet Switch
Specifications
Brand Name :
LINK-PP
Model Number :
RM3-146A8M1F
Certification :
UL,RoHS,Reach,ISO
Place of Origin :
GuangDong, China
MOQ :
50/500/1000/60K
Price :
$0.11-$24
Payment Terms :
TT,NET30/60/90 Days
Supply Ability :
180K/Month
Delivery Time :
Stock
Packaging Details :
Tray
part Number :
RM3-146A8M1F
Specification :
LPJ17206BGNL
Cross&Datasheet :
LPJ17206BGNL
Apllication :
10/100 Base-T Rj45
Original Munafactuer :
LINK-PP
Project Application :
NETWORK INTERFACE CARD
Description

RM3-146A8M1F Stackable Rj45 Female Connectors LPJ17206BGNL In Ethernet Switch

Competitor Cross Reference

Part Number

Manufacturer

Part Number

 Manufacturer Description

RM3-146A8M1F

LPJ17206BGNL

 LINK-PP

RM3-146A8M1F Stackable Rj45 Female Connectors LPJ17206BGNL In Ethernet Switch
Series Connector Type Applications Mounting Type
Connectors, Interconnects LINK-PP Rj45 10/100Mbps Thru-Hole
Orientation Termination LED Color Shielding
90° Angle (Right) Solder Yellow/ Green Shielded

Features

  • RJ-45 connector integrated with Filter
  • Size same as RJ-45 connector to save PCB board space
  • Reduce EMI radiation, Improve EMI performance
  • High performance for maximum EMI suppression.
  • ISO9001,SGS,UL,CE,REACH
  • Embedded mini PCI express Cellular modemfrom SierraWireless
  • Reduce EMI radiation, Improve EMI performance
  • Certified on all major carrier networks,attractive for network interface cards(NICS)Single port,
  • Multi-port and Stackable configurations (Thru-hole/ SMT)

  • Reduces the number of components to be placed on the board

  • Frees up board space and offers signal protection

  • Noise reduction in the system

  • Improved reliability and optimal system performance

  • Benefits of having shorter signal paths and the reliability gains from systems containing fewer components

  • Helps manufacturers reach their goals of cost reduction

Related Part

LMJ2018814100DL3T1B XMD-S-24-8-8-4-F2-DN-5-0-P XMD-1S-21-8-8-W51
LMJ20581024100DL1T3 XMD-S-24-8-8-5-F2-DN-2-0-P XMD-21-88-4-DN-1-0
LMJ20581024100DL1T3 XMD-9766-8814-8-S3LA-J XMD-8288D-B115-D
LMJ2138812S0L1T1C XMD-9766-881X-8-S3L3-Y XMD-9731-8811-2AA-D
LMJ2138812S0L1T1C XMD-S-24-8-8-M-F2-DN-5-0-P XMD-9731-8813-2AA-D
LMJ2308814 XMD-S-24-8-8-0-801 XMD-9761-2A1AC0A-241
LMJ262881413BB XMD-S-24-8-8-0-803 XMD-9766-8812-S3L3-D-A
LMJ262881413BB XMD-9731-8813-8AA-E XMD-9766-8814-S3L2-D-A
LMJ3078812J10816 XMD-9766-8816-8-S3L1-J XMD-9766-881X-S3
LMJ3078814J10816 XMD-U-24-6-4-0-9I1 XMD-9850-8811-2-S3L2-D
LMJ3078814J10816 XMD-TRJE47011AENL XMD-9850-8811-2-S3L2-D
LMJ3078815J04130 XMD-RJ31K31AB2S7-88C XMD-9850-8813-2-S3-A
LMJ3078815J04130 XMD-RJD24-S-88-1-W37-2 XMD-9850-8814-2-S3LT-A
LMJ3138812S113TC XMD-JFHB30Z00 XMD-B621S-8830-U004
LMJ3148814AB43M7L XMD-9731-8814-16AA-M XMD-JAKG00100
LMJ3918813N1001 XMD-RJ000820P8S1-D81-RS1 XMD-JALE00Z00

RM3-146A8M1F Stackable Rj45 Female Connectors LPJ17206BGNL In Ethernet Switch

RM3-146A8M1F Stackable Rj45 Female Connectors LPJ17206BGNL In Ethernet Switch

Why Choose LINK-PP

Quality

World’s Leader supplier of Integrated RJ45 Connector and Discrete Magnetic Transformers.

Original materials suppliers are selected and appointed by Tyco Electronic ,and then put into production at the standard of Tyco Electronic .

  • Manufactured under strict controls.
  • ISO 9001:2008
  • UL Certification
  • Reach Cetitifaction
  • RoHS compliance
  • OEM Of TE(Tyco) For 9 Years
  • Active Environmental policy
  • Every module tested (not just batch tested)
Main Customers

Texas Instruments INTEL SAMSUNG FLUKE EKF HUAWEI IBM CISCO
FLEXTRONICS JABIL Foxconn CANON Arduino -- --- ---

LINK-PP RJ45 Designed for BeagleBone Black of Texas Instruments

LINK-PP is the preferred supplier of Texas Instruments ,Samsung, Cisco ,Siemens and INTEL.

Welcome to visit the Texas Instruments's websit: http://www.ti.com/tool/beaglebk#0 You will look at our logo "LINK-PP”on BeagleBone Board

LINK-PP ------------ Appointed Supplier And Supporter Of Embedded System for Ti
