08C2-1X1T-03 RJ45 USB Connector LPJU4101AONL 10 / 100Base-T Embedded Board
08C2-1X1T-03 RJ45 USB Connector LPJU4101AONL 10 / 100Base-T Embedded Board
Specifications
Brand Name :
LINK-PP
Model Number :
08C2-1X1T-03 = > LPJU4101AONL
Certification :
UL,RoHS,Reach,ISO
Place of Origin :
GuangDong, China
MOQ :
50/500/1000/60K
Price :
$0.11-$24
Payment Terms :
TT,NET30/60/90 Days
Supply Ability :
180K/Month
Delivery Time :
Stock
Packaging Details :
Tray
part Number :
08C2-1X1T-03
Apllication :
10/100 Base-T,AutoMDIX
Original Munafactuer :
LINK-PP
Project Application :
Networking Solutions
Termination :
Solder
LEDs :
Orange,Green/Yellow
Description

08C2-1X1T-03 RJ45 USB Connector LPJU4101AONL 10 / 100Base-T Embedded Board

Competitor Cross Reference

Part Number

Manufacturer

Part Number

 Manufacturer Description

08C2-1X1T-03

LPJU4101AONL

 LINK-PP

08C2-1X1T-03 , RJ45 USB Connector LPJU4101AONL 10 / 100Base-T Embedded Board
Series Connector Type Applications Mounting Type
Connectors, Interconnects LINK-PP Rj45 Ti BeagleBone Black Thru-Hole
Orientation Termination LED Color Shielding
90° Angle (Right) Solder Orange,Green/Yellow Shielded, EMI Finger
Features
  • 08C2-1X1T-03 => LPJU4101AONL 【Mass Production Model】
  • 10/100 Base-TX RJ45 single port (1X1) Tab-UP with or without LEDs integrated magnetics connector
    (ICM), designed to support applications, such as Network Interface Cards (NIC), LAN-on-Motherboard (LOM),
    and PC applications.
  • Single port Tab-UP with internal magnetics for 10/100 Base-TX
    Available with or without LEDs
    Suitable for CAT 5 and 6 Fast Ethernet cable or better UTP
    Internal magnetics are 100% electrically tested for HI-POT
    and functionality
  • Internal magnetics options available
    Meets or exceeds IEEE 802.3ab standard for 1000Base-T
    350 µH minimum OCL with 8 mA bias current
    High performance for maximum EMI suppression
    Minimum 1500 Vrms isolation per IEEE 802.3 requirement

Related Part

V811-1X4T-03 MJR11D2GYA0-H33D RM6-10KARV1F 678384005
V811-1X4T-03-F MJR11D2GYA0-H34F RM7-10KARU1F 678384006
V811-1X4T-06 MJR11D2GYA0-K30Y RM9-1SKARU1F 678384104
V811-1X4T-06-F MJR11D2GYA0-K33D RMT-131AGF1F 855035001
V890-1AX1-A1 MJR11D2GYA1-H30Y RN2-10N0F41F 855045001
V890-1AX1-A1 MJR11D2GYA1-H33D RN6-10W0F51F 855055002
V890-1AX1-A1A MJR11D2GYA1-H34F RS3-2840H41A 855055113
V890-1AX1-V6 MJR11D2GYA1-K30Y RSBH20108K1F 855105017
V890-1AX1-Y5 MJR11D2GYA1-K33D RT2-10FB4K1A 855105018
V890-1CX1-46 MJR11D2NNA0-H30Y RT5-1070NM3D 855105019
V890-1CX1-A1 MJR11D2NNA0-H33D RT5-1670KC2F 855105020
V890-1CX1-Y5 MJR11D2NNA0-H34F RT5-1950K21F 855105025
V890-1G1T-A1 MJR11D2NNA0-K30Y RT7-103ABP1A 855105026
V890-1GX1-V6 MJR11D2NNA0-K33D RT7-103GG41A 855105027
V890-1GX1-Y5A MJR11S2NNA4-H34L RT7-104A8K2A 855105028
V890-1RX1-46 MJR11S2NNA4-H359 RT7-114AAG1A 855105117
V890-1RX1-A1 MJR11S2NNA4-H35V RT7-114ABP1A 855105118

Specification

08C2-1X1T-03 RJ45 USB Connector LPJU4101AONL 10 / 100Base-T Embedded Board

08C2-1X1T-03 RJ45 USB Connector LPJU4101AONL 10 / 100Base-T Embedded Board
