HFJV1-2450-L21RL Vertical RJ45 Jack 180° LPJD0011BENL Ethernet Network Analyzer
HFJV1-2450-L21RL Vertical RJ45 Jack 180° LPJD0011BENL Ethernet Network Analyzer
Specifications
Specification :
HFJV1-2450-L21RL
Brand Name :
LINK-PP
Model Number :
HFJV1-2450-L21RL
Certification :
UL,ROHS,Reach,ISO
Place of Origin :
GuangDong, China
MOQ :
50/500/1000/25K
Price :
$0.09-$1.85
Payment Terms :
TT,NET30/60/90 Days
Supply Ability :
3000000/Month
Delivery Time :
Stock
Packaging Details :
package:60 pcs in 1 tray,22 tray in 1 carton, which is 37*30*30 cm, 10 KGS (1320 pcs) of each carton
Original Munafactuer :
LINK-PP
Project Application :
NETWORK INTERFACE CARD
Cross&Datasheet :
LPJD0011BENL
Apllication :
10/100 Base-TX
part Number :
HFJV1-2450-L21RL
Description

HFJV1-2450-L21RL Vertical RJ45 Jack 180° LPJD0011BENL Ethernet network analyzer

Competitor Cross Reference

Part Number

Manufacturer

Part Number

 Manufacturer Description

HFJV1-2450-L21RL

LPJD0011BENL

 LINK-PP

HFJV1-2450-L21RL Vertical RJ45 Jack 180° LPJD0011BENL Ethernet network analyzer
Series Connector Type Applications Mounting Type
Connectors, Interconnects LINK-PP Rj45 10 Mbps Thru-Hole
Orientation Termination LED Color Shielding
180° Angle (Vertical) Solder Yellow/Green Shielded

Features

  • RJ-45 connector integrated with Filter
  • Size same as RJ-45 connector to save PCB board space
  • Reduce EMI radiation, Improve EMI performance
  • High performance for maximum EMI suppression.
  • ISO9001,SGS,UL,CE,REACH
  • Embedded mini PCI express Cellular modemfrom SierraWireless
  • Reduce EMI radiation, Improve EMI performance
  • Certified on all major carrier networks,attractive for network interface cards(NICS)Single port,
  • Multi-port and Stackable configurations (Thru-hole/ SMT)

  • Reduces the number of components to be placed on the board

  • Frees up board space and offers signal protection

  • Noise reduction in the system

  • Improved reliability and optimal system performance

  • Benefits of having shorter signal paths and the reliability gains from systems containing fewer components

  • Helps manufacturers reach their goals of cost reduction
