Discover the 747370005 SFP One Piece Cage with EMI shielding, flat EMI pins, 3.05mm press-fit tails, and closed-top design for 10 Gbps applications.

Why Choose the 747370005 SFP One Piece Cage?

The 747370005 is a one piece SFP cage used in module-to-board applications where a transceiver module must be securely mounted while maintaining shielding performance. Its copper alloy metal construction provides structural strength and EMI management, while the through-hole compliant pin termination interface supports robust board integration.

This cage is especially relevant for:

• SFP+ transceiver modules
• High-speed networking equipment
• Telecom and datacom systems
• Switches, routers, and other board-level communication hardware

Key Advantages

• EMI shielding design helps support cleaner high-speed operation
• Flat EMI pins contribute to effective grounding and contact performance
• 3.05mm press-fit tails simplify board attachment without traditional soldering
• Closed-top thermal solution supports a compact mechanical structure
• Horizontal orientation suits board layouts that need low-profile module placement
• 10.0 Gbps data rate support makes it suitable for modern high-speed interfaces

Technical Specifications – 747370005 10Gbps SFP Cage

747370005 Datasheet

SFP Cage Assembly Design Benefits

When selecting an SFP cage assembly, design teams often evaluate mechanical fit, EMI behavior, and assembly workflow. The 747370005 addresses these priorities well:

• Improved EMI management for sensitive high-speed circuits
• Press-fit termination for cleaner board assembly processes
• Stable mechanical retention with a single-port cage design
• Compatibility with horizontal layouts where board depth is limited
• Material and compliance support for global product development

This makes the part a strong candidate for OEMs, EMS providers, and procurement teams looking for a dependable SFP EMI cage for production use.

FAQ About 747370005 SFP One Piece Cage

The 747370005 SFP One Piece Cage is a well-designed EMI-shielded cage assembly for engineers who need a dependable 10 Gbps module-to-board solution with flat EMI pins, 3.05mm press-fit tails, and a closed-top horizontal structure. Its combination of mechanical stability, shielding support, and compliance-friendly construction makes it a strong choice for modern networking and communication equipment.

For teams sourcing high-speed connector and cage solutions, this part is a practical option when performance, EMI control, and board integration all matter.

1. What is the 747370005 SFP One Piece Cage used for?

It is used in module-to-board applications to house and shield SFP transceiver modules while supporting high-speed signal transmission.

2. Does the 747370005 support high-speed data rates?

Yes. The part is rated for 10.0 Gbps applications.

3. What type of mounting does this cage use?

It uses 3.05mm press-fit tails with a through-hole compliant pin termination interface.

4. Does this cage include EMI protection features?

Yes. It includes EMI shielding and flat EMI pins to support improved grounding and shielding performance.

5. Is the 747370005 suitable for compact board designs?

Yes. Its horizontal orientation, 1x1 port configuration, and closed-top design make it suitable for compact layouts.
