JXC0-1015NL Stacked RJ45 MOD JACK 8P8C R/A SHIELDED 2x1 Shielded
JXC0-1015NL Stacked RJ45 MOD JACK 8P8C R/A SHIELDED 2x1 Shielded
JXC0-1015NL Stacked RJ45 MOD JACK 8P8C R/A SHIELDED 2x1 Shielded
JXC0-1015NL Stacked RJ45 MOD JACK 8P8C R/A SHIELDED 2x1 Shielded
Specifications
Brand Name :
LINK-PP
Model Number :
JXC0-1015NL
Certification :
UL,RoHS,Reach,ISO
Place of Origin :
China
MOQ :
50/500/1000/60K
Price :
$0.11-$24
Payment Terms :
TT,NET30/60/90 Days
Supply Ability :
180K/Month
Delivery Time :
Stock
Packaging Details :
Tray
Spec :
JXC0-1015NL
Family :
2x1 Stacked RJ45
Application :
HUB, PC card, Switch, Router etc
Mounting :
Side Entry (Right Angle)
Category :
Multi-port RJ45
File :
PDF/3D/Step/IGS/Price/Cross
Description
JXC0-1015NL Stacked RJ45 MOD JACK 8P8C R/A SHIELDED 2x1 Shielded

Quick Details:
1. Gender: female Socket to Ethernet
2. 2X1 Port stacked RJ45 Jack
3. Magnetic RJ45 Jack
4. JXC0-1015NL Pin to Pin Compatible

Product parameters:

2x1 RJ45 Connector ,Without LED,Tab Up/Tab Down,RoHS
LINK-PP Part Number JXC0-1015NL
Application-Lan ETHERNET(NoN PoE)
Contact Mating Area Plating GOLD 6u"/15u"/30u"
Cores per Port NO
Diodes NO DIODES
LED Option WITHOUT
Latch TAB UP/TAB DOWN
Number of Ports 2X1
PCB Mount Angle SIDE ENTRY
Package Height (mm) 25.50
Package Length (mm) 28.50
Package Width (mm) 17.28
Pin Type THT SOLDER
RoHS Compliant YES-RoHS-5 WITH LEAD IN SOLDER EXEMPTION
Search YES
Shield EMI Tabs WITH
Speed without Magnetics
Temperature - 40 TO + 85℃
Turns Ratio RX 1CT:1CT
Turns Ratio TX 1CT:1CT

JXC0-1015NL Stacked RJ45 MOD JACK 8P8C R/A SHIELDED 2x1 Shielded


Applications:

Used for networking and communication equipments such as HUB, PC card, Switch, Router, PC Mainboard, SDH, PDH, IP Phone, xDSL modem

Competitive Advantage:
20 years production experience,
1100 staff,
100% test
Flexible delivery time
