54602-908LF / 54602-9F08LF Unshielded Single Port RJ45 Modular Jack LPJE182NNL
54602-908LF / 54602-9F08LF Unshielded Single Port RJ45 Modular Jack LPJE182NNL
54602-908LF / 54602-9F08LF Unshielded Single Port RJ45 Modular Jack LPJE182NNL
54602-908LF / 54602-9F08LF Unshielded Single Port RJ45 Modular Jack LPJE182NNL
Specifications
Brand Name :
LINK-PP
Model Number :
54602-908LF
Certification :
UL,ROHS,Reach,ISO
Place of Origin :
China
MOQ :
50/500/1000/25K
Price :
$0.05-$1.28
Payment Terms :
TT,NET30/60/90 Days
Supply Ability :
4200K-PCS/Month
Delivery Time :
Stock
Packaging Details :
50pcs/tray,1200pcs/carton
Part Number :
54602-908LF / 54602-9F08LF
Cable System :
CAT3
Product Type :
Modular
Gender :
RJ45 Jack (Female)
Shielding :
Unshielded
Configuration :
1x1
Description

54602-908LF / 54602-9F08LF
RJ45 Modular Jack
Single Port RJ45
LPJE182NNL
Parameter Specification
Part Number 54602-908LF
Product Category Modular / Ethernet Connectors
Product Type Connector (Jack / Female)
USOC Code RJ45
Configuration 1×1
Positions / Contacts per Port 8P8C
Number of Ports 1 Port
Number of Contacts 8 Contacts
Number of Positions 8 Positions
Shielding Unshielded
Performance Category Category 3 (Cat 3)
Mounting Style Through Hole (THT)
Mounting Angle Right Angle
Termination Style Solder
Tab Direction Tab Down
Color Black
Contact Material Copper Alloy
Contact Plating Gold
Current Rating 1 A
Voltage Rating 1 kV
Insulation Resistance 500 MΩ
Mating Cycles 250 Cycles
Flammability Rating UL 94V-0
Application 10BASE-T Ethernet
Packaging Tray

54602-908LF / 54602-9F08LF Unshielded Single Port RJ45 Modular Jack LPJE182NNL

Technical Characteristics

The RJ45 Modular Jack features a black PBT insulator with a UL 94-V0 flammability rating, ensuring flame-retardant performance suitable for high-reliability applications. The contacts are stamped from phosphor bronze and plated with gold, providing excellent conductivity and corrosion resistance. Shielding is constructed from nickel-plated bronze for effective electromagnetic protection. The product supports a quality class of 500 mating cycles, ensuring mechanical durability.

Environmental Performance

  • Operating Temperature Range: –40°C to +85°C
  • Compliance: Lead-free and fully RoHS compliant

Electrical Performance

  • Current Rating: 1.5 A
  • Working Voltage: 120 VAC
  • Insulation Resistance: > 1000 MΩ
  • Dielectric Withstanding Voltage: 1000 VAC/min
  • Contact Resistance: ≤ 20 mΩ

Standards & Certifications

  • Certified to: E324776
  • Soldering Process: Compatible with JEDEC lead-free wave soldering process
  • Packaging: Tray format for secure handling and assembly

Applications

  • CompactPCI Switches and PXI Switches
  • Bus Analyzers and Bus Exercisers
  • Programmable Automation Controller (PAC) Modules
  • Transformer Test Equipment
