40~1050MHz GPON/EPON/GEPON fttx passive optic receiver OR100 for triple-play
40~1050MHz GPON/EPON/GEPON fttx passive optic receiver OR100 for triple-play
Specifications
Brand Name :
RITEL
Model Number :
40~1050MHz GPON/EPON/GEPON fttx passive optic receiver OR100,OR100WF,OR100WD for triple-play
Certification :
CE
Place of Origin :
CHINA
MOQ :
100PCS
Price :
$1.00~$10.00
Payment Terms :
T/T, Paypal, Western Union
Supply Ability :
5K~10Kpcs per months
Delivery Time :
5~7 days
Packaging Details :
Carton, box
material :
plastic, zinc-alloy
frequency :
40~1050MHz
output level :
68dB
type :
passive receiver
model :
mini box
output :
adaptor, pigtail, box
Description

40~1050MHz GPON/EPON/GEPON fttx passive optic receiver OR100,OR100WF,OR100WD for triple-play

Features

■ No power required.

■ Original high quality fast response PD.

■ Built-in filter and WDM option.

■ Adaptor, pigtail, zinc-alloy and box available.

Specifications

Item Unit Parameter Remark
Optic Parameter
Work Wavelength nm 1260~1620 ORN100
nm 1540~1563 ORN100WF
Pass Wavelength nm 1310, 1490 ORN100WD
Input Optic Power dBm -14~ +2
Suggested Optic Power dBm -12~0
Return Loss dB ≥55
Interface SC/APC SC/PC
Link Parameter
C/N dB ≥51
C/CTB dB ≥65
C/CSO dB ≥60
RF Parameter
Frequency Range MHz 40~1050
Flatness dB ±0.75
Output Level dBuV 68 Pin=-1dBm
Return Loss dB ≥14
Output Port 1 F female
Impedance Ω 75
General
Dimension mm 65W*22D*10H 82W*49D*22H
Weight Kg 0.03 0.05

Order Information

Model Input wavelength CATV Operating wavelength Data Pass Input Output
ORN100 1310 or 1550 1260~1620 SC/APC
ORN100WF 1310,1490/1550 1540~1563 SC/APC
ORN100WD 1310/1490 SC/APC SC/UPC

OEM/ODM/EMS is welcome!
