Security Turnstile Gate Equipped with Advanced Sensors and Mechanisms to Deliver Accurate Entry Verification and Control
Security Turnstile Gate Equipped with Advanced Sensors and Mechanisms to Deliver Accurate Entry Verification and Control
Security Turnstile Gate Equipped with Advanced Sensors and Mechanisms to Deliver Accurate Entry Verification and Control
Security Turnstile Gate Equipped with Advanced Sensors and Mechanisms to Deliver Accurate Entry Verification and Control
Security Turnstile Gate Equipped with Advanced Sensors and Mechanisms to Deliver Accurate Entry Verification and Control
Security Turnstile Gate Equipped with Advanced Sensors and Mechanisms to Deliver Accurate Entry Verification and Control
Security Turnstile Gate Equipped with Advanced Sensors and Mechanisms to Deliver Accurate Entry Verification and Control
Security Turnstile Gate Equipped with Advanced Sensors and Mechanisms to Deliver Accurate Entry Verification and Control
Security Turnstile Gate Equipped with Advanced Sensors and Mechanisms to Deliver Accurate Entry Verification and Control
Security Turnstile Gate Equipped with Advanced Sensors and Mechanisms to Deliver Accurate Entry Verification and Control
Specifications
Payment Terms :
T/T,L/C
Power :
40W
Brand Name :
Sikerui
Certification :
CE / RoHS / FCC
Dimension :
1400 * 120 * 980mm
Material :
304 stainless steel
Thickness :
1.0mm
Channel width :
600-900mm
Voltage :
220V
Model Number :
SSTBZ-04
MOQ :
1PCS
Supply Ability :
5000 Units Per Month
Place of Origin :
China
Packaging Details :
Wooden Box
Delivery Time :
5-7days
Price :
$800-1500
Description
Security Turnstile Gate
Luxury Swing Barrier Speed way Turnstile Barrier Gate offering effective security solutions tailored to meet the needs of modern access control systems.
Product Overview
This intelligent swing barrier, model SSTBZ-04, is designed for efficient and secure access control in various environments. Constructed from robust 2.0mm thick steel plate with paint, it ensures durability and long-lasting performance. Its versatile traffic mode settings and electromechanical anti-collision protection make it a reliable solution for managing pedestrian flow.
Ideal for indoor and outdoor use (with canopy), this swing barrier can withstand a wide range of environmental conditions, from -20°C to +60°C. With a service life of over 5 million continuous opening and closing cycles, it offers exceptional value and reliability.
Key Benefits
  • Durable Construction: Made from 2.0mm thick steel plate with paint for long-lasting use
  • Versatile Traffic Management: Supports one-way, two-way, and free traffic modes
  • Secure Access Control: Compatible with ID/IC card readers and button gate opening
  • Electromechanical Anti-Collision: Provides enhanced safety and protection
  • Wide Operating Temperature: Functions reliably in temperatures from -20°C to +60°C
Target Applications
  • Office buildings
  • Factories and industrial facilities
  • Transportation hubs
  • Other locations requiring controlled pedestrian access
Technical Specifications
Parameter Value
Model Number SSTBZ-04
Dimension 1400 * 120 * 980mm
Thickness 1.0mm
Channel Width 600-900mm
Voltage 220V
Power 40W
Material 304 stainless steel
Steel Plate Thickness 2.0mm
Cylinder Diameter 168mm
Height 1050mm
Traffic Speed ≤30 people/minute
Driving Motor Voltage DC 24V brushless motor
Working Environment Temperature -20℃ ~ +60℃
Relative Humidity ≤95%, no condensation
Communication Interface RS485 electrical standard
Communication Distance ≤ 1200m
Opening Time 0.8S
Service Life Continuous opening and closing for more than 5 million times
Working Environment Indoor and outdoor (with canopy)
Noise during device operation ≤60 dB
