PP/PE 1 /5/10/ 25/50/ 75 /100/150/200 Filter Cloth
PP/PE 1 /5/10/ 25/50/ 75 /100/150/200 Filter Cloth
PP/PE 1 /5/10/ 25/50/ 75 /100/150/200 Filter Cloth
PP/PE 1 /5/10/ 25/50/ 75 /100/150/200 Filter Cloth
PP/PE 1 /5/10/ 25/50/ 75 /100/150/200 Filter Cloth
PP/PE 1 /5/10/ 25/50/ 75 /100/150/200 Filter Cloth
PP/PE 1 /5/10/ 25/50/ 75 /100/150/200 Filter Cloth
PP/PE 1 /5/10/ 25/50/ 75 /100/150/200 Filter Cloth
PP/PE 1 /5/10/ 25/50/ 75 /100/150/200 Filter Cloth
PP/PE 1 /5/10/ 25/50/ 75 /100/150/200 Filter Cloth
Specifications
Model NO. :
PH00023
Type :
House Filter Bag
Materials :
Polyester , Polypropylene, Mesh Fabric
Micron Sizes :
0.5 Micron to 1000 Micron
Width :
100mm to 2100mm
Thickness :
1mm to 2.5mm
Transport Package :
Standard Export Packing
Specification :
1m x 1m x 1m
Trademark :
RUIQI
Origin :
China
HS Code :
5911900
Production Capacity :
5000PCS / Week
MOQ :
100
Price :
2.2
Description
PP/PE 1 micron /5 micron/10 micron / 25 micron/50micron/ 75 miron /100micron/150micron/200 micron filter cloth

Quick Detail:
Â
Material : PP or PE,polyester, polypropylene
Micron rating : 0.5um ~800um
Good anti-abrasion
High temperature grade
Anti-acid ,anti-alkali, chemical resistance
High porosity ,good air permeability
Laminated compound,grads counterchange

Â

Parameter of PP Liquid filter bag
PP/PE 1 /5/10/ 25/50/ 75 /100/150/200 Filter Cloth

PP/PE 1 /5/10/ 25/50/ 75 /100/150/200 Filter Cloth

PP/PE 1 /5/10/ 25/50/ 75 /100/150/200 Filter Cloth
PP/PE 1 /5/10/ 25/50/ 75 /100/150/200 Filter Cloth
PP/PE 1 /5/10/ 25/50/ 75 /100/150/200 Filter Cloth

Â

Specifications:

1. Material:PP non-wowen Felt.

2. 100 micron or as your request.
3. With straw string.
4. Use for powder or air filter .
5. size, shape, packing can be customized.


Â
#1-----(7"x16") -----¢180*410mm
Â
#2-----(7" x 32") -----¢180*810mm
Â
#3-----(4"x 8 1/4") -----¢102*210mm
Â
#4-----(4"x 14") -----¢102*356mm

Â



Â

Material PE,PP,NMO,PTFE
Cuff PP Lock, Stainless steel
Relative filtration pore size 0.5, 1,5, 10, 25, 50, 100, 200 µm
Type various specifications
Airtight method: Hot Melt, reverse sewing
Effective filtration area various specifications
Others special requirement of diameter and collar extension can be customized

Â

PRODUCTÂ CODE:

Component

Elongation@50N/5cm

Fibre

100%PP

Longitudinal(%)

Transverse(%)

Scrim

100%PP

<3%

<3%

Weight(g/m²)

500

Operating Temperatures

Thickness(mm)

2.0

Continuous(°C)

Surge(°C)

Density(g/cm3)

0.25

130

150

Mean Air Permeability
(L/dm².min)

150-250

Max Dry Shrinkage in 90 minutes:(150°C)(%)

<1%

Breaking Strength

Surface Treatment

Heat Setting,  Singed,
Represent add stainlessÂ
steel fibers

Longitudinal(N)

Transverse(N)

>1000

>1200

Â
Â
Notices:
Â
1. Materials avaliable: polyester, polypropylene
2. construction: welded or sewn
3. collar type: steel ring or plastic ring
4. finishing treatment: singed, calendared, heat set
5. Size available: standard and custom size.

Â
Application fields:
Â
1) The fume and smoke treatment and particle removing system in metallurgy plant, alloy plant, steel works, moulding factories, fire-retardant factories and power stations
Â
 2) Fume filtration, tiny particle recycle and division of liquid and solid in aluminum electro analysis, tin, zinc, cooper and other rare metals
Â
3) Smoke filtration in garbage burning, coal-feed boiler and liquidized laid boilers
Â
4) Division of liquid, solid and tiny particle recycle in chemicals, coke, carbon, dyestuff, pharmacy and plastics
Â
5) Asphalt concrete mixture, cements, ceramics, building materials, lime and plaster
Â
6) Dust treatment, purification and collection in electronics, mining, foodstuff processing, flour and timber processing.

RIQI (HANGZHOU ) FILTER TECHNOLOGY CO.,LTD . has grown up to be one of leading manufacturer on dust filtration&spare parts in China.We have imported filter needle felt production line ASSELIN from France and we can produce very good quality non-woven products according customer's requirment.
Â
Based on 8 needle felt production line ,our annual production ability can achieved 20,000 square meters per day . We can produce a large range of various filter fabric, such as polyester filter fabric, Acrylic filter fabric, Fiberglass filter fabric, PPS filter fabric, Nomex ,P84 ,PTFE ,woven filter fabric and so on.
Â
The most important thing is that we introduced German high technology to develop the first filter bag production line in China. Which help most filter bag production factory save a lot of human lab our cost but promote the work effection . The advanced technology and simple operation way of automatic filter bag production line has won a lot of customer's praise.
