Mems Dynamic Inclinometer For Railway / Drilling / Ship Navigation
Mems Dynamic Inclinometer For Railway / Drilling / Ship Navigation
Mems Dynamic Inclinometer For Railway / Drilling / Ship Navigation
Mems Dynamic Inclinometer For Railway / Drilling / Ship Navigation
Mems Dynamic Inclinometer For Railway / Drilling / Ship Navigation
Mems Dynamic Inclinometer For Railway / Drilling / Ship Navigation
Specifications
Brand Name :
Rion
Model Number :
HDA437T
Certification :
CE
Place of Origin :
Guangdong, China
MOQ :
1
Price :
$128/Pieces
Payment Terms :
T/T, PayPal
Supply Ability :
5000/month
Delivery Time :
5-7 days
Packaging Details :
box
Power supply :
9~36v
dynamic accuracy :
0.1deg
resolution :
0.01deg
static accuracy :
0.05deg
acceleration range :
±8g
gyro range :
±250°/s
weight :
165g
name :
Dynamic 3 Axis Tilt Transducer Anti Vibration Inclination Sensor
Description

HDA437T MEMS Dynamic 3 Axis Tilt Transducer Anti-Vibration Inclination Sensor for Railway/Drilling/Ship Navigation

▶ KEY FEATURES

★ Range (Roll angle ±180°, pitch angle ±90°, azimuth angle ±180°)

★ Dynamic accuracy: ± 0.1°

★ Static accuracy: ± 0.05°

★ RS485/232/TTL output Optional

★ Wide temperature operation -40~+ 85℃

★ DC 9~6V wide voltage input

★ Resolution 0.01°

★ IP67/IP68 Protection level Optional

▶ PRODUCT APPLICATION

★ High vibration impact gravel equipment

★ Railway locomotive monitoring

★ Oil drilling equipment

★ Shield pipe jacking application

★ Shield pipe jacking application

★ Geological equipment tilt monitoring

★ Underground drilling rig attitude navigation

★ Ship navigation attitude measurement

★ Satellite communication vehicle attitude detection

★ Orientation measurement based on inclination angle

★ Various engineering machinery inclination measurement

▶ SPECIFICATIONS

HDA436T CONDITION INDEX
Measure range -

Roll ±180°, pitch ±90°, azimuth ±180°

(initial value at power-down is 0°)
Measure axis - X axis / Y axis / Z axis
Resolution - 0.01°
Static accuracy @25℃ ± 0.05°
Dynamic accuracy(RMS) @25℃ ± 0.1°
Gyro range - ±250°/s
Zero bias stability (10s mean) - 8.5°/h
Zero Bias Instability(allan) - 4.5°/h
Angle random walk coefficient(allan) - 0.25°/sqrt(h)
Acceleration range - ±8g
Bias stability(10s mean) - 0.02mg
Bias instability(allan) - 0.005mg
Speed random walk coefficient(allan) - 0.005m/s/sqrt(h)
Zero point temp. coefficient -40～85℃ ±0.01°/℃
Sensitivity temp. coefficient -40～85℃ ≤100ppm/℃
Power-on startup time 1S
Response time 0.01S
Output signal RS485/RS232/TTL
Electromagnetic compatibility According to EN61000 and GBT17626
MTBF ≥ 98000 hours / time
Insulation resistance ≥100 Megohm
Impact resistance 100g @ 11ms,3 axial direction (half sinusoid)
Anti-vibration 10grms,10～1000Hz
Waterproof level

standard configuration: IP67

optional configuration: IP68 or IP68 with anti-corrosion cable
Cable Standard without wiring, optional 2m M12 aviation plug with PVC unshielded cable
Weight ≤165g (excluding cables)

Mems Dynamic Inclinometer For Railway / Drilling / Ship Navigation

Mems Dynamic Inclinometer For Railway / Drilling / Ship Navigation

INSTALLATION METHOD

Mems Dynamic Inclinometer For Railway / Drilling / Ship Navigation

▶ MECHANICAL PARAMETERS

○ Connector: M12 aviation plug 5P connector

○ Protection level: IP67

○ Shell material: frosted aluminum alloy

○ Installation: Four M4 screws
