AKG392 4000Hz Output Triaxial RS232 MEMS Vibration Sensor
AKG392 4000Hz Output Triaxial RS232 MEMS Vibration Sensor
Specifications
Theory :
MEMS
working temp. :
-40~85 celcius degree
Resonance frequency :
2.4kHz
weight :
<40g
Output :
Digital Sensor
Brand Name :
RION
Model Number :
AKG394-40
Certification :
CE, ROHS
Place of Origin :
Guangdong, China
MOQ :
1
Price :
$268.00/Pieces >=1 Pieces
Payment Terms :
T/T
Supply Ability :
500 Piece/Pieces per Month
Delivery Time :
1 weeks for samples
Packaging Details :
1pcs/box
Output Interface :
RS232/RS485/TTL
Usage :
Measure vibraiton amplitude acceleration
operation voltage :
9~36V
Description

AKG392 4000Hz Output Triaxial RS232 MEMS Vibration Sensor

AKG392 4000Hz Output Triaxial RS232 MEMS Vibration Sensor

AKG392 three-axis vibration sensor is a product independently developed and produced, applied in wide range of applications, which covers many fields such as vibration testing and impact testing. The product adopts digital interface output with options as RS232/485/TTL. Different address codes can be set, multiple Vibration sensor can be installed in series for long distance, which is convenient for multi-point measurement and data analysis. Internal FFT processing can directly output the object vibration frequency and speed and Amplitude, convenient for users to analyze data.
The users can change the sampling frequency according to the actual frequency of the object to improve the frequency measurement accuracy. AKG392 is a single crystal silicon capacitive sensor, which consists of a silicon chip processed by micro-machines, a low-power ASIC for signal adjustment, a microprocessor for storing compensation values, and a temperature sensor. This product has low power consumption, calibration, sturdy structure, and stable output. The new electronic configuration provides solid-state power for reset and protection from over-voltage. The long-term stability and deviation of the scale factor in the full-scale range are typically less than 0.1%. This series of products have the characteristics of sturdy structure, low power consumption, and excellent deviation stability, ensuring stable output reliability.

▶ MAIN FEATURE
  • Three axes (X, Y, Z)
  • Output signal: RS232; RS485; TTL
  • Power supply voltage: 9-36V
  • Impact resistance: 2000G
  • Working temperature: -40°C ~ +85°C
  • Storage temperature: -40°C ~ +85°C
  • Size: L34.3×W34.3×H38.5mm
  • Excellent deviation stability, good environmental performance (shock, vibration and temperature)
▶ APPLICATION
  • Medical equipment
  • Bridge
  • Automobile
  • Road roller
  • Wind power generation
  • Large machinery, engines
  • Low-frequency vibration and automatic monitoring
  • Traffic system monitoring, roadbed analysis and high-speed railway fault detection
Product Description
▶ PERFORMANCE
AKG392 PARAMETERS UNIT
Range ±2 ±4 ±8 ±10 ±20 ±40 g
Bias calibration <1 <1 <1 <1 <1 <1 mg
Measure axis X,Y,Z X,Y,Z X,Y,Z X,Y,Z X,Y,Z X,Y,Z axis
Power on/off repeatability <2 <2 <2 <2 <2 <2 mg(max)
Bias temperature coefficient 0.15 0.15 0.15 0.75 0.75 0.75 %/℃(typical)
Resolution/threshold (@ 1Hz) < 1 < 1 < 1 < 1 < 1 < 1 mg(max)
Non-linearity <0.5 <0.8 <1 <1 <1 <1 % FS(max)
Bandwidth (3DB) 500 500 500 500 500 500 Hz
Cross axis sensitivity 1 1 1 2 2 2 %
Transverse vibration sensitivity ratio 1 1 2 5 5 5 %
Resonance frequency 2.4 2.4 2.4 5.5 5.5 5.5 kHz
Output rate 5Hz,10Hz,25Hz,50Hz,100Hz,200Hz,500Hz,1000Hz
Output Interface RS232/RS485/TTL
Protocol RION 68 protocol and MODBUS RTU protocol
Reliability MIL-HDBK-217,Grade 2
Impact resistance 100g@11ms, 3 Axial Direction (Half Sinusoid)
Recovery Time <1ms(1000g, 1/2 sin 1ms, Impact on the i-axis)
Vibration 20g rms,20~2000Hz (Random noise, o, p, i acts on each axis for 30 minutes)
Input(VDD_VSS) 9~36 VDC
Operating current consumption <60mA @ 12 VDC
Connector Industry standard M12 connector
Weight

Product net weight: 82g,

Magnetic base: 48g,

L-shaped adapter plate 20g
Size

Product size: 34.3*34.3*38.5mm

Magnetic adsorption base size: 34.23*34.23*6mm

L-shaped adapter plate size: 36*44*4mm

AKG392 4000Hz Output Triaxial RS232 MEMS Vibration Sensor

AKG392 4000Hz Output Triaxial RS232 MEMS Vibration Sensor
