YJLV 0.6/1kV Aluminum Alloy Power Cable with XLPE Insulation and Steel Tape Armor for 3+1 Core and 4 Core Applications
YJLV 0.6/1kV Aluminum Alloy Power Cable with XLPE Insulation and Steel Tape Armor for 3+1 Core and 4 Core Applications
YJLV 0.6/1kV Aluminum Alloy Power Cable with XLPE Insulation and Steel Tape Armor for 3+1 Core and 4 Core Applications
YJLV 0.6/1kV Aluminum Alloy Power Cable with XLPE Insulation and Steel Tape Armor for 3+1 Core and 4 Core Applications
Specifications
Model Number :
0.5MM/0.75MM/1MM/1.5MM/2.5MM/4MM/6MM
Brand Name :
Rihui Cable
Place of Origin :
Shandong, China
Price :
$1/meters 1-9 meters
Conductor Material :
Aluminum
Insulation Material :
PVC/XLPE
Rated Voltage :
0.6/1kV
Size :
4*240 mm² + 1*120 mm², 3*185 mm² + 1*95 mm², 3*70 mm² + 1*35 mm², 2*10 mm², 3*16 mm² + 1*10 mm², 4*70 mm² + 1*35 mm², 2.5/4/6/10/16/25/35mm
Application :
Power Distribution, Construction, Power Station
IP Level :
IP67
Jacket :
PVC
Type :
Low Voltage, YJLHV/YJLHV22
Working Temperature :
90°C
Product name :
Aluminum Alloy Cable
Conductor :
Aluminum
Insulation :
XLPE PE PVC
Color :
Customer's Requirment
Certificate :
ISO9001/CCC
Core :
1/2/3/4/3+1/5/3+2/4+1
Keywords :
Power Cable
Description

**YJLV 0.6/1kV Aluminum Core XLPE Insulated Steel Tape Armored PVC Sheathed Power Cable**

- Rated Voltage: 0.6/1 kV
- Conductor: Plain annealed stranded aluminum (Class 2, compact or sectoral)
- Insulation: Cross-linked Polyethylene (XLPE), rated 90°C continuous operation
- Core Identification:
– 3+1 Core: Brown, Black, Grey + Green/Yellow (earth)
– 4 Core: Brown, Black, Grey, Blue
– 5 Core: Brown, Black, Grey, Blue + Green/Yellow
- Filler/Bedding: Extruded PVC or PP ropes
- Armor: Double helical galvanized steel tape (STA)
- Outer Sheath: Black PVC Type ST2; flame-retardant, UV-resistant, oil-resistant
- Available Sections: 2.5 mm² – 400 mm² (full range)
- Standards: GB/T 12706.1-2008, IEC 60502-1, BS 5467, AS/NZS 5000.1
- Max. Short-circuit Temperature: 250°C (5 s max. duration)
- Minimum Installation Temperature: -15°C
- Operating Temperature Range: -15°C to +90°C

Features
Excellent electrical properties and thermal stability
Steel tape armor provides strong mechanical protection and rodent resistance
Suitable for direct burial, underground ducts, cable trays, indoor/outdoor fixed installation
Flame performance meets IEC 60332-1; ZR- (flame-retardant) and WDZ- (low-smoke zero-halogen) versions available upon request

Application
Power transmission and distribution in industrial facilities, commercial buildings, residential projects, tunnels, substations and infrastructure projects requiring armored protection.
