Waterproof USB Connector Panel Mount IP68 USB Type C Female Connector
Waterproof USB Connector Panel Mount IP68 USB Type C Female Connector
Waterproof USB Connector Panel Mount IP68 USB Type C Female Connector
Waterproof USB Connector Panel Mount IP68 USB Type C Female Connector
Specifications
Brand Name :
RG
Model Number :
RG-USB
Certification :
CE Rohs IP68
Place of Origin :
China
MOQ :
20PCS
Price :
negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
10000PCS month
Delivery Time :
within 2 weeks when order confirmed
Packaging Details :
usually 40*30*30cm carton ,we also can according customer request.
Mame :
Waterproof USB Connector
IP degree :
IP68
Material :
TPU Cu
Colour :
Black
Lock way :
screw
Working Temperature :
-40C to 105C
Current :
1.5A
Voltage :
60V
Waterproof circle :
Silica gel
Durability :
≥500 times
Description

Waterproof Swift USB Type-C Connectors IP68 degree

Waterproof USB Connector Panel Mount IP68 USB Type C Female Connector

Specifications:
Cable specification: 0.15m㎡-0.2m㎡/26-24AWG
Diameter range: Φ5.5mm～Φ7mm
Contact number: 4pin
Rated Current (A): 1.5A
Contact resistance: <30mΩ
Withstanding Voltage (AC.V) 1 minute: 1000V
Insulation resistance: ＞500MΩ
Protection level: IP67
Durability: ≥500 times
Working temperature: -40℃～80℃
Connecting mode: Snap locking
Housing, the insulating parts: High-performance engineering plastics
Hardware: copper
Pin needles: gold-plated
Waterproof circle: Silica gel
Flammability rating: UL94-V0

Product types
waterproof usb connector USB 3.0 panel mount connector
Contact number
9
Protection level
IP67
Cable specification
0.15mm2 ~0.2mm2 /26~24AWG
Wire diameter range
Φ5.5mm ~Φ7mm (cable can be customized)
Current rating(A)
1.5A
Voltage resistance
1000V, 3.0-100v
Contact resistance
<30mΩ
Insulation resistance
>500MΩ
Durability
≥500 mating&unmating cycles
Temperature rating
-40°C~80°C
Method of connecting cable
Quick bayonet connection
Features
Gold plated contacts, 1/2 bayonet lock, easy installation
Material of insulated parts
High-performance engineering plastics
Hardware metal
Zinc alloy(pearl hard chromium)
Contact pin
Copper alloy(gold-plated)
Sealing
Silica gel
Flame rating
UL94-V0

Waterproof USB Connector Panel Mount IP68 USB Type C Female Connector

Waterproof USB Connector Panel Mount IP68 USB Type C Female Connector

Rigoal Connector Waterproof USB Connectors include Micro-USB, USB 3.0/3.1, and USB 2.0 devices with IP67 / IP68 waterproof ratings, featuring copper alloy and gold-plated contacts. This family of USB connectors includes those with and without strain relief, as well as a variety of mating styles including screw thread and quick lock. RG Waterproof USB Connectors are available as receptacles and with cables for overmolded applications.
