250V M12 4 Pin Waterproof Connector Plug Cable Straight Assembly PA GF
250V M12 4 Pin Waterproof Connector Plug Cable Straight Assembly PA GF
250V M12 4 Pin Waterproof Connector Plug Cable Straight Assembly PA GF
250V M12 4 Pin Waterproof Connector Plug Cable Straight Assembly PA GF
250V M12 4 Pin Waterproof Connector Plug Cable Straight Assembly PA GF
250V M12 4 Pin Waterproof Connector Plug Cable Straight Assembly PA GF
250V M12 4 Pin Waterproof Connector Plug Cable Straight Assembly PA GF
250V M12 4 Pin Waterproof Connector Plug Cable Straight Assembly PA GF
250V M12 4 Pin Waterproof Connector Plug Cable Straight Assembly PA GF
250V M12 4 Pin Waterproof Connector Plug Cable Straight Assembly PA GF
250V M12 4 Pin Waterproof Connector Plug Cable Straight Assembly PA GF
250V M12 4 Pin Waterproof Connector Plug Cable Straight Assembly PA GF
Specifications
Brand Name :
RIGOAL
Model Number :
m12 waterproof connector
Certification :
CE，ROHS，ISO
Place of Origin :
Shen zhen，China
MOQ :
10
Price :
negotiable
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
100000
Delivery Time :
7~14
Packaging Details :
1.Our packaging:each pcs in one PE bag, then put in a small carton. 2.According to customer request.
Connection Type :
Connection Type Panel Mount/Screw type/ Solder type
Number of Contacts :
3/4/5/6/8 Pin
Gender :
Male/Female
Orientation :
Straight/Angled
Termination :
Soldering/PCB
Rated Current :
4A
Operating Voltage :
250V
Temperature Range :
-25°C ~ + 80°C
IP Rating :
IP67
Description

waterproof ip67 straight assembly 4pin sensor conector plug cable panel mounted pcb a d code female m12 4 pin connector

250V M12 4 Pin Waterproof Connector Plug Cable Straight Assembly PA GF250V M12 4 Pin Waterproof Connector Plug Cable Straight Assembly PA GF

General Infomation
Standard IEC 61076-2-101 Insulation Resistance ≥100MΩ
Ambient Temperature -25℃~+90℃ Contact Resistance ≤5mΩ
Connector Insert Plastic(PA+GF) Shielding Unavailable
Connector Contacts Plastic(PA+GF) Seal/O-ring Epoxy resin/FKM
Coupling Nut/Screw Plastic(PA+GF) Mating Endurance >500 cycles
IP Rating IP68/IP69K in locked condition Certificate UL/CE/ROHS/IP67/REACH/IP68

The M12 series features sensor and actuator connectors with locking thread for electronics automation, process control,

and commercial electronics.

We offer many different cable connectors, panel mount receptacles, field attachable/ installable connectors and various accessories.

Our connectors have industry standard A/B/C/D/S/T/X cording, for both screw locking and quick-locking styles.
