Drilling Equipment BOP Spare Parts API 16A Annular Bop Packing Element
Drilling Equipment BOP Spare Parts API 16A Annular Bop Packing Element
Drilling Equipment BOP Spare Parts API 16A Annular Bop Packing Element
Drilling Equipment BOP Spare Parts API 16A Annular Bop Packing Element
Drilling Equipment BOP Spare Parts API 16A Annular Bop Packing Element
Drilling Equipment BOP Spare Parts API 16A Annular Bop Packing Element
Drilling Equipment BOP Spare Parts API 16A Annular Bop Packing Element
Drilling Equipment BOP Spare Parts API 16A Annular Bop Packing Element
Drilling Equipment BOP Spare Parts API 16A Annular Bop Packing Element
Drilling Equipment BOP Spare Parts API 16A Annular Bop Packing Element
Specifications
Brand Name :
Topland
Model Number :
Packing Element
Certification :
API 16A
Place of Origin :
China
MOQ :
1
Price :
3000-8000 USD PER PIECE
Payment Terms :
T/T, L/C, Western Union
Supply Ability :
5,000 M Per Month
Delivery Time :
10~20 days
Packaging Details :
Standard Package
Type :
Packing Element
Material :
Alloy
Working Pressure :
3000psi to 10000psi
Surface Treatment :
Spray-Paint
Operation Pressure :
Manual
Condition :
New
HS code :
8431431000
Transport Package :
Wooden Package
Description

Drilling Equipment BOP Spare Parts API 16A Annular Bop Packing Element

BOP Spare Parts Packing Element description:

The packing element is made up of the independent innovation rubber based polymer alloy material and the high strength metal frame, which conforms to the USA 16A, SATM D412, D624, D2240 and D471 standard. It is suitable for the drilling work on the oil field, which shares a high cost performance comparing to the other same type packing elements. And the repair seal kits are equipped.

Packing Element Technical Parameter of BOP Spare Parts:

- Pipe ram rubber specification

BOP Model Variable Ram Rubber (in)
Type Bore
mm(in)		 Working pressure MPa(psi) Temperature grade (°C) 2 3/8"-3 1/2" 2 7/8"-5" 3 1/2"-5" 4 1/2"-5 1/2" 4 1/2"-7" 5"-7"
S 179(7 1/16) 35(5000) -18°C -- 121°C √
70(10000) √
279(11) 35(5000) √ √
70(10000) √ √
105(15000) √
346(13 5/8) 35(5000) √ √ √ √ √
70(10000) √ √ √ √
105(15000) √ √ √ √
540(21 1/4) 14(2000) √
21(3000) √
35(5000) √
U 279(11) 35(5000) √ √ √
70(10000) √ √ √
105(15000)
346(13 5/8) 35(5000) √ √ √ √ √
70(10000) √ √ √ √ √
105(15000) √ √

- Physics performance of ram rubber

Item Inspection item Technical specification ≤35MPa Technical specification ≥70MPa
1 toughness A 75±5 85±5
2 300% tensile toughness Mpa ≥10 ≥10
3 tensile toughness Mpa ≥19.6 ≥19.6
4 elongation rate % ≥250 ≥200
5 permanent distortion % ≤25 ≤20
6 aging rate120ºC×24h ≥0.6 ≥0.6
7 brittleness temperatureºC ≤-18 ≤-18
8 brittleness temperature KN/m ≥40 ≥40
9 brittleness temperature Mpa ≥4 ≥4

- High performance rubber physics specification(HNBR material, Cameron refer to Cameron type material specification)

Item Inspection item Technical specification
1 toughness A 90±5
3 tensile strength Mpa ≥18
4 elongation rate % ≥100
5 aging rate90ºC×24h ≥0.75
6 permanent compressing rate % ≤20

Blowout Preventers Spares
BOP Control Systems • Accumulators • Remote
• Choke Panels • Control Panel
• Closing Unit • Sand Line
• Brake • Spare Parts
• Hammer Unions • Swivel Joints
• Manifolds • Wireline Units
• Mud Pumps
BOP Stack Spares • Annular BOP • Kill Lines
• BOP Control Hoses • Manual Gate Valve
• Casing Head Housing • Packing Elements
• Casing Head Spool • RAM Assemblies
• Check Valve • RAM Rubbers
• Diverters • Ring Gaskets
• Double Ram BOP • Rotating BOP
• Drilling Spool • Single Ram BOP
• Flanges • Spherical BOP
• Hydraulic Gate Valve • Type U
Choke Manifold • Choke Control Console • Manual Gate Valve
• Drilling Choke • Pressure Gauge
• Gate Valves • Standpipe Pressure Gauges
• Hydraulic Gate Valve • Transmitters
Pressure Gauges • Degasser • Mud Valves
• Mud Tanks

Drilling Equipment BOP Spare Parts API 16A Annular Bop Packing ElementDrilling Equipment BOP Spare Parts API 16A Annular Bop Packing ElementDrilling Equipment BOP Spare Parts API 16A Annular Bop Packing Element

FAQ

1. Who are we?
Topland is an integrated supplier established in 2008. We are a global group of oilfield supplies with excellent teams in more than 5 countries. such as UAE, Kuwait, Iran and Saudi Arabia. We cooperated with ADES, ECDE, EDC, SOCAR-AQS, PDL, SAKSON, ONGC etc.


2. How can we guarantee quality?
Always a double requirements and drawing checking before the production;
Always final Inspection before shipment;
3. What can you buy from us?
Drilling rig equipment and the related spares for the oil and natural gas industries. Like Rig Components, Drawworks Spare parts and Mud Pump Spare parts, Hydraulic Disc Brake,Solids Control Equipment, Drilling and Fishing Tools,Wellhead Control Equipment,Drilling Accessories, Cementing Equipment and Tools etc.

4. Why should you choose us?
4-1. Professional & Efficient, Customer Focus, Win-win Cooperation

4-2. Fast Quote, Competitive price & within shortest lead time

4-3. Complete Range of products, like spare parts which are interchangeable with most of the well-known OEM equipment.

4-2. Order tracking service

5. How is the packing?

All the packing will meet the strict export packing requirement, we surely know how important the beautiful and firm packaging to the goods.

6. What is your terms of payment?

A: Generally by T/T, 30% advance payment, the balance 70% payment should be paid before delivery. We support EXW, FOB, FCA, CFR, CIF, CIP, DAP, DDU and DDP INCO Terms.
