Specifications
Brand Name :
Topand
Model Number :
SP-40B
Certification :
ISO
Place of Origin :
China
MOQ :
1
Price :
negotiable
Payment Terms :
L/C, D/A
Supply Ability :
5 per day
Delivery Time :
15 days
Packaging Details :
Wooden Box
Warranty: :
1 Year
Weight (KG): :
300kg
Usage: :
Well Drilling
Product name: :
Vacuum Pump
Certification: :
API
Core Components: :
Pump
Description

Oilfield Solids Control Equipment High Capacity Solid Vacuum Pump Vacuum Sludge Pump

Description:
Vacuum Degasser is adapted to get rid of various cut-in gases in the drilling fluids. Vacuum degasser is very important for returning mud gravity, stabilizing mud viscosity and reducing drilling cost. Therefore, it works as one type mud cleaning equipment. As it is placed after the shale shaker, so we call it second stage mud cleaning equipment in mud recycling system. At the same time vacuum degasser can be used as a heavy-power agitator.

Features:
1.Self-contained degasser unit operation without feeding pump.
2.Liquid Level Sensor for safety operation.
3.Degasser have another function like a big size agitator for mixing mud before feeding to desander desilter.
4.Technical and spare parts support in many countries.

Tehnical Parameter:

ModeISP-40BSP-20BSP-10B
Max Capacity (m³/h)40m³/h20m³/h10m³/h
Inlet/Outlet Size(Inch)4"(114mm)4"(114mm)3"(89mm)
Vacuum Degree85Kpa/25 inch HG(Mercury Column)
Max Suction Distance (m)50m
Max Discharge Distance (m)1000m500m
Max Solids Content80%
Max Solids Size (mm)75mm50mm
Pressure Request550Kpa-785Kpa (80-
114PSI)
550Kpa-690Kpa (80-100PSI)
Air Demand17m³/min (600CFM)8m³/min(280CFM)4.3 m³/min(150CFM)
Weight(kg)892kg386kg320kg
Dimension1690*1468*1983mm1421*900*1448mm1283*800*1370mm


Oilfield Solids Control Equipment High Capacity Solid Vacuum Pump Vacuum Sludge Pump

FAQ

1. Who are we?
Topland is an integrated supplier established in 2008. We are a global group of oilfield supplies with excellent teams in more than 5 countries. such as UAE, Kuwait, Iran and Saudi Arabia. We cooperated with ADES, ECDE, EDC, SOCAR-AQS, PDL, SAKSON, ONGC etc.


2. How can we guarantee quality?
Always a double requirements and drawing checking before the production;
Always final Inspection before shipment;
3. What can you buy from us?
Drilling rig equipment and the related spares for the oil and natural gas industries. Like Rig Components, Drawworks Spare parts and Mud Pump Spare parts, Hydraulic Disc Brake,Solids Control Equipment, Drilling and Fishing Tools,Wellhead Control Equipment,Drilling Accessories, Cementing Equipment and Tools etc.

4. Why should you choose us?
4-1. Professional & Efficient, Customer Focus, Win-win Cooperation

4-2. Fast Quote, Competitive price & within shortest lead time

4-3. Complete Range of products, like spare parts which are interchangeable with most of the well-known OEM equipment.

4-2. Order tracking service

5: How is the packing?

All the packing will meet the strict export packing requirement, we surely know how important the beautiful and firm packaging to the goods.

6: What is your terms of payment?

A: Generally by T/T, 30% advance payment, the balance 70% payment should be paid before delivery. We support EXW, FOB, FCA, CFR, CIF, CIP, DAP, DDU and DDP INCO Terms.
