Specifications
Brand Name :
kailite p10 outdoor led screen
Model Number :
P10 outdoor led screen
Place of Origin :
Guangdong, China
MOQ :
12
Pixel pitch :
10mm
Module size :
320mm*160mm
Physical density :
10000 dots/sqm
LED chip :
SMD3535
Module resolution :
32*16
Module power :
70w
Maximum power consumption :
900w
Average power consumption :
450w
Cabinet size :
W960m×H960mm
Weight :
32kg/panel
Drive method :
1/2 scan
Refresh rate :
1200Hz
White balance brightness :
≥6500cd
Operating temperature :
-40℃~+65℃
Ingress protection :
Front:IP67; Back:IP65
Description

Outdoor advertising high brightness P10 outdoor led display screen billboard

Main Features of P10 outdoor led sceen

1) More than 6500cd/m² brightness, Be seen clearly even with strong sunshine

2) 100% Full waterproof, no worry about woring in rainy day
3) Support almost all format of video files, images ect.
4) 3 years warranty and life time maintance

Product Description

P10 Outdoor LED Display Screen 10mm Pixel Pitch 6500cd Brightness

P10 Outdoor LED Display Screen 10mm Pixel Pitch 6500cd Brightness

P10 Outdoor LED Display Screen 10mm Pixel Pitch 6500cd BrightnessP10 Outdoor LED Display Screen 10mm Pixel Pitch 6500cd Brightness

Parameters

ItemP10 outdoor led screen
ColorFull color
Use environmentoutdoor
Pixel pitch10mm
Module size320*160mm
Physical density 10000dots/square meter
Pixel configuration 1R1G1B
LED chipSMD3535
Module resolution32*16
Module power 70w
Recommended viewing distance10-70m
Best viewing angle H: 140°; V:140°
Maximum power consumption900w
Average power consumption450w
Cabinet size W960m×H960mm
Standard cabinet resolution96*96
Weight 32kg/panel
Driving method 1/2 Scan, Constant Current
Video frame rate ≥60 Hz
Rate refresh ≥1200Hz
White balance brightness≥6500cd
Operating temperature/Humidity -40℃~+65℃
Ingress protection Front:IP 67; Back:IP65
Input voltage 110-220V AC±10%
Gray scale /Color Display Colors ≥16.7Million
Brightness control Manual/Automatic
Input signal RF,S-VIDEO,RGBHV,YUV,YC & COMPOSITION,etc
Control systemAsynchronous or synchronous
MBTF>5000 hours
Life time >100,000 Hours
The rate<0.0001

Why choose us

1) Well-experienced
A) our factory specialized in this industry for 11 years, and i worked in this industry for 5 years.
B) we have much experience and many cases in this industry abroad.

2) No after sale worries.
a) we provide full process technical support for installation guidance and debugging etc service.
b) 2 years warranty and lifetime maintenance service.
c) send our engineer for onsite guidance based on your requirments

3) Save your time and energy.
A) Complete solution
B) Consider and solve potential issues before you realized.
C) Respond to you immediately for all your questions
D) full process of follow up and feedback to you the status of your order.

4) Save shipping cost for you.
We have some well cooperated shipping agents for Sea shipping; Air shipping and Express. they
could give their most competitive price.

5) Almost all your questions we have already experienced and well solved, So for all your issues, we could provide professional solutions.

6) You will get one more partner or friend. In our mind, you are more than a client.

P10 Outdoor LED Display Screen 10mm Pixel Pitch 6500cd BrightnessP10 Outdoor LED Display Screen 10mm Pixel Pitch 6500cd Brightness
Packaging & Shipping

P10 Outdoor LED Display Screen 10mm Pixel Pitch 6500cd Brightness

P10 Outdoor LED Display Screen 10mm Pixel Pitch 6500cd Brightness

Company Information

P10 Outdoor LED Display Screen 10mm Pixel Pitch 6500cd BrightnessP10 Outdoor LED Display Screen 10mm Pixel Pitch 6500cd BrightnessP10 Outdoor LED Display Screen 10mm Pixel Pitch 6500cd Brightness

P10 Outdoor LED Display Screen 10mm Pixel Pitch 6500cd Brightness

FAQ

Q1: Are you factory or trading company?
We are factory with 8000 square meters working plant, we welcome you to visit our factory.

Q2: Apart from P10 model, do you have any other models for option?
Yes sure,
for indoor we could provide you with P10, P6, P7.62, P5, P4.8, P4, P3.9, P3, P2.9, P2.5, P2,
P1.9, P1.8, P1.6, P1.5, P1.2.
For outdoor we could provide with P10, P8, P6, P6.25, P5, P4, P4.8, P3.9, P3

Q3: What pixel pitch should I choose on my display?
A: it's determined mainly by the viewing distance, and the size of the display screen, if you don't know,
just leave us a inquiry.

Q4: how do i know how many models i need for my project?
A: you could tell us the size of your led screen, then we will let you konw the quantity.

Q5: How to install the led modules?
A: we provide two install ways,
1)one is with screws, you can install the led modules on cabinet by screws;
2) the other is with Magnets, you could fix the modules to the frame in this way.

Q6: What about your quality?
A: Regarding quality we take it extremely serious, and thanks to our strick quality control proceess
our quality is good and guaranteed.

Q7: What about the warranty?
A:Two year warranty and lifetime maintenance

Q8: What about the lead time?
A:Orders less than 50 square meter display, lead time is 15-18 working days.

Q9: Can I order a sample?
A:Yes,We welcome customers to order samples to check our product quality of our products and
service.


P10 Outdoor LED Display Screen 10mm Pixel Pitch 6500cd Brightness
