Specifications
Brand Name :
SCXK
Model Number :
SCXK-G3.91
Certification :
CE. Rohs .FCC ,UL,TUV
Place of Origin :
China
MOQ :
5sqm can be available
Price :
Can be Negotiable
Payment Terms :
D/P, L/C, D/A, T/T, Western Union, MoneyGram
Supply Ability :
1000 sqm/month can be available
Delivery Time :
7-10days can be finished and sent to you
Packaging Details :
wooden box packaged or flight case packaged
Material :
plastic
Dot density :
32768dots/sqm
Cabinet size: :
500 x1000mm
Cabinet resolution :
128dots x128 dots
LED standard :
1R1G1B
Usage :
semioutdoor usage
LED lamp :
SMD1921
Description

Semi Outdoor Full Color Transparent LED Display SMD1921 3 Years Warranty

Quick details:

cabinet size:500mm x1000mm

Dot density:32768 dots/sqm

led standard:1R1G1B

Brightness:≥4000 cd/sqm

Usage:semioutdoor

Warranty: 3 years

Lifeuse :10 years

SCXK has been specialized in LED field since 2005. We are a leading manufacturer an provider of technical solution of full color indoor and outdoor led display,rental LED display, led modules where in Shenzhen city ,Guang dong province,China.

Specification:

LED Lamps Type SMD1921(High Brightness LEDs)
LED Standard Real Pixel(1R1G1B)
Red Wavelength 625-630nm
Green Wavelength 515-530nm
Blue Wavelength 465-475nm
LED Module Pixel Pitch

G3.91-7.8125mm
LED Cabinet Cabinet Size 500mmx1000mm
Cabinet resolution 128x128 dots
Cabinets Material Special Gum and plastic
LED Display Pixel Density 32768 pixels/sq.m
Drive IC MBI5124
Power Supply Series connection
Brightness >4500cd/sqm
Display Color 16.7million
Viewing Angle 160°(Horizontal),110°(Vertical)
Best Viewing Distance 10.4m~200m
Max Power Consumption 600 w/sq.m
Average Power Consumption 300 w/sq.m
Weight 16kgs/sq.m
Refresh Rate 2500hz
Input Voltage AC220V/50H or AC110V/60H
Output Voltage DC5V,40A
Grey Scale Levels 16bit
Display Colors R(1024) x G(1024) x B(1024)
MTBF 10,000 hours
Life-span 100,000 hours
Protection Level IP54
Failure percentage of leds less than 0.0003
Working Temperature -5℃~65℃
Working Humidity 10%~99%
Control System Control method Synchronization & Asynchronization
Control System (software) linsn
Software LED Studio
Input Signal MPG/MPEG/MPV/MPA/AVI/VCD/SWF/RM/RA/RM/ASF/BMP/GIF/PCX/TXT/DOC.etc
PC Operating system Microsoft Windows 7, 98, 2000, XP and Vista

2025 Hot Transparent Led Window Display Mini Transparent Led Display Glass Window Transparent Led Display

Competitive advantage:

1. Whats your payment term? How long it takes to delivery?

A1. We accept T/T and L/C, For both T/T and L/C, At least 30% deposit in advance, and the rest 70% before delivery.Our average Production time is 10 days, after receiving the deposit.

2. What's the control system?

A2. For synchronization control. We use Nova, Linsn Or Colorlight control system.

The led display will be packaged with flight case or wooden box.

The cabinet is made very elegant and durable .It can satisfy all the circumstance requirements. And the power supply is still very important.

It’s related to lifeuse of the product.Generally ,we adopt the iron and steel cabinet, meanwell power supply or chuanglian power supply.
