P4 Indoor LED Video Wall Screen 4mm SMD2121 IP43 Aluminum Cabinet
P4 Indoor LED Video Wall Screen 4mm SMD2121 IP43 Aluminum Cabinet
P4 Indoor LED Video Wall Screen 4mm SMD2121 IP43 Aluminum Cabinet
P4 Indoor LED Video Wall Screen 4mm SMD2121 IP43 Aluminum Cabinet
P4 Indoor LED Video Wall Screen 4mm SMD2121 IP43 Aluminum Cabinet
P4 Indoor LED Video Wall Screen 4mm SMD2121 IP43 Aluminum Cabinet
P4 Indoor LED Video Wall Screen 4mm SMD2121 IP43 Aluminum Cabinet
P4 Indoor LED Video Wall Screen 4mm SMD2121 IP43 Aluminum Cabinet
P4 Indoor LED Video Wall Screen 4mm SMD2121 IP43 Aluminum Cabinet
P4 Indoor LED Video Wall Screen 4mm SMD2121 IP43 Aluminum Cabinet
P4 Indoor LED Video Wall Screen 4mm SMD2121 IP43 Aluminum Cabinet
P4 Indoor LED Video Wall Screen 4mm SMD2121 IP43 Aluminum Cabinet
Specifications
Brand Name :
SCXK
Model Number :
P4
Certification :
CE/ROHS/FCC/ISO/UL
Place of Origin :
Shenzhen in China
MOQ :
2 pcs
Price :
negotiation
Payment Terms :
Western Union,MoneyGram,D/P,T/T,L/C
Supply Ability :
5000sqm per month
Delivery Time :
7-10 working days after receive your payment
Packaging Details :
flight case, wooden case, carton, it is up to you.
Pixels :
4mm
Led Type :
SMD2121
Display Function :
Video/Image
Waterproof :
IP43
Cabinet :
die catsing aluminum
MBI :
5124
viewing angle :
H:100 V:50
voltage :
DC5V
module size :
320*160mm
cabinet size :
640*640mm
Description
P4 Full Color Indoor LED Video Wall Screen 80×40 Module Resolution Advertising Billboards
Product Specifications
Attribute Value
Pixels 4mm
Led Type SMD2121
Display Function Video/Image
Waterproof IP43
Cabinet Die casting aluminum
MBI 5124
Viewing Angle H:100° V:50°
Voltage DC5V
Module Size 320×160mm
Cabinet Size 640×640mm
4mm IP43 Rental Indoor Full Color LED Display Screen 512×512mm Cabinet
Main Features
  • Super-light weight and Ultra-thin: Only 8 kg in weight for 500×500mm panel, 14kg for 500×100mm panel, 80mm in thickness
  • With special designed mask and plastic frame, the surface is very smooth and viewing angle is very large
  • With driver IC MBI 5124 from Taiwan, it's of high refresh rate of 1920 Hz/s. The driver IC can be upgraded to ICN2038 with a refresh rate over 3840 Hz/s
  • With fast lock system, easy to install and dismantle
  • Flexible installation, can be stacked on floor or hung on truss
  • Adjustable curve. With angle regulator, the arc can be adjusted to 10° concave to 10° convex
  • The same panel is compatible with P3.91, P4.81, P5.95 and P6.25 outdoor and indoor LED display
Production Process
  1. Incoming Inspection
  2. SMD
  3. Plug-in
  4. Wave Soldering
  5. After Welding
  6. Testing
  7. Semi Finished Aging
  8. Module Assembly
  9. Gluing
  10. Finished Aging
  11. Detection Finishing Warehousing
Technical Specifications
Parameter Specification
Lamp size 2121
Resolution/mm 4
Pixel configuration RGB 3 in 1
Pixel density/pixels/m² 40000/m²
Module resolution 80×40
Module size/mm 320×160
View distance ≥0.5m
Single point brightness adjust Can be added
Single point color adjust Can be added
White balance brightness >1000cd/㎡
Color temperature 6500K-9500K
Horizontal view angle 120°
Vertical view angle 60°
Signal Process bit 10 or 14 bit
Grey process 1024×1024×1024/16834×16834×16834/65536×65536×65536
Control distances Internet cable:100m, multimembrane:500m, monofilm:5km
Driving mode Constant driving current
Scanning mode 1/20
Frame rate 60Hz
Refresh frequency >3000Hz
Control mode Computer synchronous
Brightness adjusted range Manual, automatic operation, stepless continuous adjusted
255 steps. No grey loss
Out of control point <1/10000
Working hours ≥72hours
Mean Time Between Failure >5000hours
Life time 100000hours
Life-all-white (brightness halving) 50000hours
Environment temperature range Operating temperature range: -20-45℃
Storing temperature range: -30-65℃
P4 Indoor LED Video Wall Screen 4mm SMD2121 IP43 Aluminum Cabinet
Packaging and Shipping

Wooden case or flight case package are available. Shipping by sea, air or DHL, multiple shipping ways for your choice.

Our Advantages
  • Professional Manufacturer of LED display
  • OEM service, No MOQ
  • Easy installation, regular items in Stocks
  • Offering free design drawing as requested
  • Remote controlling and adjusting are available
  • Wooden case or flight case options available
  • Your reply will be replied within 24 hours
  • Fast delivery: Usually 6-8 working days
  • Excellent R&D team, factory Price and assure you quality goods
