P10 Multi Color Big Outdoor Led Display Screens Waterproof IP65 Billboard
P10 Multi Color Big Outdoor Led Display Screens Waterproof IP65 Billboard
P10 Multi Color Big Outdoor Led Display Screens Waterproof IP65 Billboard
P10 Multi Color Big Outdoor Led Display Screens Waterproof IP65 Billboard
P10 Multi Color Big Outdoor Led Display Screens Waterproof IP65 Billboard
P10 Multi Color Big Outdoor Led Display Screens Waterproof IP65 Billboard
Specifications
Brand Name :
SCXK
Model Number :
P10
Certification :
CE/ROHS/FCC/ISO/UL
Place of Origin :
China
MOQ :
10sqm
Price :
negotiation
Payment Terms :
T/T, Western Union, D/A, D/P
Supply Ability :
5000sqm per month
Delivery Time :
7-10 working days after receive your payment
Packaging Details :
flight case, wooden case, carton, it is up to you.
Product name :
P10 Outdoor multi color led display panels cubic pillar waterproof led billboard
Usage :
advertising outdoor
Pitch :
10mm
protect degree :
IP65 waterproof
Brightness :
6000-10000nits
Working Tem./Hum. :
-20-50℃
Description

P10 Multi Color Big Outdoor Led Display Screens Waterproof IP65 Billboard

♦ Features

1. Personalized and complete solution for your case

2. factory price and good quality
3. Convenient and fast installation;Easy maintenance
4. 3 years warranty

♦ Product specification

outdoor SMD P10
Resolution/mm 10
Pixel configuration 1R1G1B
Pixel density/pixels/m² 10000/m²
Module resolution 32*16
Module size/mm 320*160
View distance 9-400m
Single point brightness adjust Can be added
Single point color adjust Can be added
White balance brightness >8000cd/㎡
Color temperature 6500K-9500K
Horizontal view angle 120(degrees)
Vertical view angle 60(degrees)
Signal Process bit 10 or 16bit
Grey process 1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distances Internet cable:100m, multimembrane:500m, monofilm:2km
Driving mode Constant driving current
Scanning mode (1/4)
Frame rate 60Hz
Refresh frequency >3500Hz
Control mode Computer synchronous
Brightness adjusted range

Manual, automatic operation, stepless continuous adjusted

255 steps. No grey loss
Out of control point <1/10000
Working hours ≥72hours
Mean Time Between Failure >5000hours
Life time 100000hours
Life-all-white(brightness halving) 50000hours
Environment temperature range Operating temperature range: -20-45℃
Maximum power:/㎡ <900W
Average power:/㎡ <350W
Self-check technology

LED spot self-check, communications check, power check,

temperature monitor(need customization)
Remote monitoring

Remote supervision and control, record potential fault,

send out warning signs to the operators.(need customization)
Software environment WindowsNT,Windows1999,WindowsXP
Luminous point width between centres Deviation<3%
Brightness uniformity <10%
Color uniformity(chromaticity coordinate) ±0.003
Power supply request AC85-264V(50Hz-60Hz)
Contrast (1000:1)
System protection Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working) working:10-95%
Humidity(storing) storing:10-95%

P10 Multi Color Big Outdoor Led Display Screens Waterproof IP65 Billboard

♦ Production process:

1) Incoming Inspection→2) SMD→3) Plug-in

→4) Wave Soldering→5) After Welding→6) Testing

→7) Semi Finished Aging→8) Module Assembly

→9) Gluing→10) Finished Aging→11) Detection Finishing Warehousing

♦ Packaging and shipping

Wooden case or flight case package are available.

Shipping by sea,air or DHL,multiple shipping ways for your choice.

P10 Multi Color Big Outdoor Led Display Screens Waterproof IP65 Billboard

♦ Description:

• With sensitive control system, it can adjust screen brightness automatically according to the lighting change of indoor and outdoor, saving energy to reduce your operating costs greatly.
• High refresh rate and high gray make the picture more realistic, which meets the demand of high visual quality of commercial usage.
• The advertising contents can be changed at any time, for different customers and various advertisements.
• you can know the display operation anytime, anywhere.
• it can turn on and turn off the screen by software timing or manually at any time, achieving unattended function.
