Specifications
Brand Name :
SCXK
Model Number :
P8
Certification :
CBCE/ROHS/FCC/ISO/UL
Place of Origin :
CHINA
MOQ :
13 sqm
Price :
negotiation
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
5600 sqm month
Delivery Time :
7-15 working days
Packaging Details :
flight case, wooden case, carton, it is up to you.
Pixel density/pixels/m² :
15625/m²
Module size/mm :
256x128
Scanning mode :
(1/4)
Refresh frequency :
>3840Hz
Installation Site :
Football Stadium
Color :
Full color
Resolution :
32x16dots
Density: :
10000dots/sqm
Brightness: :
7000cd
led chip :
Nationstar
control system :
Nova ,huidu,colorlight,linsn
warranty :
5years
Description

p10 p8 p6 p5 outdoor waterproof football stadium led display screen 960x960mm outdoor led display

Perfect Brightness and Chromaticity Calibration


Perfect calibration between brightness and chromaticity delivers best picture quality at every place. The brightness difference is set to less than 2%, and chromaticity difference is less than 0.005. You may also adjust the brightness and chromaticity as per your choice.

Get Every Detail in Picture

We spend some time with every detail of the product, so that you can enjoy every detail of your marketing pictures. The pixel-perfect pictures are a treat to watch. It means, you will not miss any detail in the picture, video or text displayed on the screen.

outdoor p10 soft module with 960x960mm Waterproof 7000cd Sports Perimeter Led Display,waterproof,1920hz,good quatity

♦ Product specification

outdoor SMD P8
Resolution/mm 8
Pixel configuration 1R1G1B
Pixel density/pixels/m² 15625/m²
Module resolution 32x16
Module size/mm 256x128
View distance 7-400m
Single point brightness adjust Can be added
Single point color adjust Can be added
White balance brightness >8000cd/㎡
Color temperature 6500K-9500K
Horizontal view angle 120(degrees)
Vertical view angle 60(degrees)
Signal Process bit 10 or 16bit
Grey process 1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distances Internet cable:100m, multimembrane:500m, monofilm:2km
Driving mode Constant driving current
Scanning mode (1/4)
Frame rate 60Hz
Refresh frequency >3000Hz
Control mode Computer synchronous
Brightness adjusted range

Manual, automatic operation, stepless continuous adjusted

255 steps. No grey loss

Out of control point <1/10000
Working hours ≥72hours
Mean Time Between Failure >5000hours
Life time 100000hours
Life-all-white(brightness halving) 50000hours
Environment temperature range Operating temperature range: -20-45℃
Maximum power:/㎡ <950W
Average power:/㎡ <350W
Self-check technology

LED spot self-check, communications check, power check,

temperature monitor(need customization)

Remote monitoring

Remote supervision and control, record potential fault,

send out warning signs to the operators.(need customization)

Software environment WindowsNT,Windows1999,WindowsXP
Luminous point width between centres Deviation<3%
Brightness uniformity <10%
Color uniformity(chromaticity coordinate) ±0.003
Power supply request AC85-264V(50Hz-60Hz)
Contrast (1000:1)
System protection Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working) working:10-95%
Humidity(storing) storing:10-95%

outdoor p10 soft module with 960x960mm Waterproof 7000cd Sports Perimeter Led Display,waterproof,1920hz,good quatity


♦ Production process:

1) Incoming Inspection→2) SMD→3) Plug-in

→4) Wave Soldering→5) After Welding→6) Testing

→7) Semi Finished Aging→8) Module Assembly

→9) Gluing→10) Finished Aging→11) Detection Finishing Warehousing

♦ Packaging and shipping

Wooden case or flight case package are available.

Shipping by sea,air or DHL,multiple shipping ways for your choice.

outdoor p10 soft module with 960x960mm Waterproof 7000cd Sports Perimeter Led Display,waterproof,1920hz,good quatityoutdoor p10 soft module with 960x960mm Waterproof 7000cd Sports Perimeter Led Display,waterproof,1920hz,good quatity

FAQ

Q1: Why choose us?

A1.1: Company Info: Signic has been in LED industry with more than 10 years expericence,

our sales marketing areas cover a lot of countries in America,Europe,East and other area,which

are more than 90 countries regions.

A1.2: R&D Team: Signic has the professional R&D team, and launch new products according

to the customers' needs every year or even each quarter.

A1.3: Manufacturing: Signic has strict QC control and manufacturing management process,

which enable our products high quality and stable working performance.

A1.4: Service: Signic has have specialized technicians before and after sales. And strong

marketing team to offer youthe solutions 10/24 anytime.

Q2: What’s the warranty of your LED Display?

A2: We offer 2 years warranty for our different LED Display Screen series, 100,000 hours life span

for the LED Lamps,and life time technology support with 10/24 service if you have any question with

LED Screen.

Q3: What’s your payment term? How long takes to delivery?

A3: We accept payment online through Alibaba, or offline to our company account by T/T bank,

PayPal, and other payment options for your convenience.

Usually, 30% deposit in advance, and 70% balance be paid before delivery.

The average lead time is 20days.
