Specifications
Brand Name :
Shichuangxinke
Model Number :
SCXK-P12
Certification :
CE RoHS FCC CCC TUV UL
Place of Origin :
China ,Guang Dong
MOQ :
negotiation
Price :
negotiation
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
3000sqm per month
Delivery Time :
7-10 working days after deposit payment received
Packaging Details :
wooden box flight case, wooden case, carton, it is up to you.
Resolution/mm :
12
Pixel configuration :
1R1G1B
Scanning Mode :
1/4 scanning
Module Size :
192x192mm
cabinet size :
960x768mm
certificates :
CE RoHS FCC CCC UL
application :
stadium,airport,shopping mall,street advertising
material :
aluminum
warranty :
3-5 years
Description


Light weight P12 Outdoor Full Color LED Display Advertising Multi Signals With CE / RoHS

Introduction:

1.CE&RoHS certificate
2. 36 months warranty and Life long free tech-support
3.Excellent contrast ratio, high resolution/high definition
4.Perect uniformity and no mosaic
5. Waterproof IP65
6. Light weight and easy to install
7. Available models: P10, 12, 16, 20, 25, 31.25, ect.


Advantages:

1. We have the advantage of a full range of LED display production

2: Goods supply from indoor and outdoor P10, P8, P6, P4,P3,P3.91, P4.81, P2, P2.5, P1.976 have sufficient inventory, at the same time has high quality, let you buy at ease, use at ease
3. We have round-the-clock online customers to help customers and give customers product performance introduction, as
wellasproduct advantage analysis; According to the actual situation and the use of the situation, for the customer
evaluation,choosethe most reasonable scheme
4: At the same time, we can provide customers with professional training on the operation and maintenance of the led display
system Display troubleshooting

Specifications

outdoor DIP P12
Resolution/mm 12
Pixel configuration 1R1G1B
Pixel density/pixels/m² 6944/m²
Module resolution 16x16
Module size/mm 192x192MM
View distance 14-300m
Single point brightness adjust Can be added
Single point color adjust Can be added
White balance brightness >7500cd/㎡
Color temperature 6500K-9500K
Horizontal view angle 120(degrees)
Vertical view angle 60(degrees)
Signal Process bit 10 or 16bit
Grey process 1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distances Internet cable:100m, multimembrane:500m, monofilm:2km
Driving mode Constant driving current
Scanning mode 1/4 SCANNING
Frame rate 60Hz
Refresh frequency >3000Hz
Control mode Computer synchronous
Brightness adjusted range Manual, automatic operation, stepless continuous adjusted
255 steps. No grey loss
Out of control point <1/10000
Working hours ≥72hours
Mean Time Between Failure >5000hours
Life time 100000hours
Life-all-white(brightness halving) 50000hours
Environment temperature range Operating temperature range: -20-45℃
Self-check technology LED spot self-check, communications check, power check,
temperature monitor(need customization)
Remote monitoring Remote supervision and control, record potential fault,
send out warning signs to the operators.(need customization)
Software environment WindowsNT,Windows1999,WindowsXP
Luminous point width between centres Deviation<3%
Brightness uniformity <10%
Color uniformity(chromaticity coordinate) ±0.003
Power supply request AC85-264V(50Hz-60Hz)
Contrast (1000:1)
System protection Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working) working:10-95%
Humidity(storing) storing:10-95%




Our Service
LED display project support and local surveys are available from the moment the customer starts budgeting for the LED display project.
Provide customized LED screen software and hardware products according to customer requirements.
Provide LED screen technical training (factory or on-site) for different customers.
Drawings such as steel structure drawings and connection drawings are available after the order.
Whenever there is a software operation problem, we will provide timely online service and we will solve the problem as soon as possible in the process of cooperation with customers.
