20x20mm Metal Core PCB Built On aluminum substrate with 1W/MK Dielectric
20x20mm Metal Core PCB Built On aluminum substrate with 1W/MK Dielectric
20x20mm Metal Core PCB Built On aluminum substrate with 1W/MK Dielectric
20x20mm Metal Core PCB Built On aluminum substrate with 1W/MK Dielectric
20x20mm Metal Core PCB Built On aluminum substrate with 1W/MK Dielectric
20x20mm Metal Core PCB Built On aluminum substrate with 1W/MK Dielectric
20x20mm Metal Core PCB Built On aluminum substrate with 1W/MK Dielectric
20x20mm Metal Core PCB Built On aluminum substrate with 1W/MK Dielectric
20x20mm Metal Core PCB Built On aluminum substrate with 1W/MK Dielectric
20x20mm Metal Core PCB Built On aluminum substrate with 1W/MK Dielectric
20x20mm Metal Core PCB Built On aluminum substrate with 1W/MK Dielectric
20x20mm Metal Core PCB Built On aluminum substrate with 1W/MK Dielectric
20x20mm Metal Core PCB Built On aluminum substrate with 1W/MK Dielectric
20x20mm Metal Core PCB Built On aluminum substrate with 1W/MK Dielectric
Specifications
Brand Name :
Bicheng
Model Number :
BIC-772.V1.0
Certification :
UL, ISO9001, IATF16949
Place of Origin :
CHINA
MOQ :
1PCS
Price :
USD9.99-99.99
Payment Terms :
T/T
Supply Ability :
5000PCS per month
Delivery Time :
8-9 working days
Packaging Details :
Vacuum bags+Cartons
Base material :
1W/MK dielectric material
Layer count :
Single side
PCB thickness :
1.6mm ±0.16
PCB size :
20 x 20mm=1PCS
Solder mask :
Black
Silkscreen :
N/A
Copper weight :
1oz
Surface finish :
Immersion gold
Description

Aluminum Core PCB Metal Core Printed Circuit Board On 1W/MK Dielectric With Immersion Gold
(PCB’s are custom-made products, the picture and parameters shown are just for reference)
General description
This is a type of metal core PCB built on aluminum substrate with 1W/MK dielectric material for the application of inverter circuit. It's 1.6 mm thick, black solder mask. Pads are plated by a layer of immersion gold. The base material is used from ITEQ, entire board supplying 1 PCB up. They're fabricated per IPC 6012 Class 2 using supplied Gerber data. Every 50 boards are packed for shipment.
Parameter and data sheet
PCB SIZE 20 x 20mm=1PCS
BOARD TYPE Aluminum core PCB, IMS type
Number of Layers Single sided PCB
Surface Mount Components YES
Through Hole Components NO
LAYER STACKUP copper ------- 35um(1oz)
1W/MK dielectric material
Aluminum 5052
TECHNOLOGY
Minimum Trace and Space: 20 mil / 20 mil
Minimum / Maximum Holes: 3.5 / 3.5 mm
Number of Different Holes: 1
Number of Drill Holes: 4
Thermal resistance(°C/W) ≤0.45
Breakdown Voltage(VDC) 4000
Impedance Control no
BOARD MATERIAL
Thermal conductivity 1W/MK dielectric material, MCPCB
Final foil external: 1 oz
Final foil internal: 0 oz
Final height of PCB: 1.6mm ±0.16
PLATING AND COATING
Surface Finish Immersion Gold
Solder Mask Apply To: Top. 12µm Minimum.
Solder Mask Color: Black
Solder Mask Type: LPSM
CONTOUR/CUTTING Punching
MARKING
Side of Component Legend N/A
Colour of Component Legend N/A
Manufacturer Name or Logo: Marked on the board in a conductor and leged FREE AREA
VIA no via
FLAMIBILITY RATING UL 94-V0 Approval MIN.
DIMENSION TOLERANCE
Outline dimension: 0.0059" (0.15mm)
Board plating: 0.0030" (0.076mm)
Drill tolerance: 0.002" (0.05mm)
TEST 100% Electrical Test prior shipment
TYPE OF ARTWORK TO BE SUPPLIED email file, Gerber RS-274-X, PCBDOC etc
SERVICE AREA Worldwide, Globally.
20x20mm Metal Core PCB Built On aluminum substrate with 1W/MK Dielectric
Features and benefits
Improve the power density and reliability of the device;
Optimization combination of power circuit and control circuit;
Reduce the operating temperature of the equipment;
Effective heat dissipation reduces the operating temperature of the module and prolongs the service life;
Strict WIP inspection and monitoring as well as working instruction;
Meeting your PCB needs from prototype to mass production;
Powerful PCB capabilities support your research and development, sales and marketing;
8000 types of PCB per month;
Quick CADCAM checking and free PCB quotation;
Applications
Power supply equipment
A filter electric circuit
Solid relay
Outdoor lighting for expressway
